Description

Technical data sheet for YAMATAKE EST0240Z05WBX00:
Display size: 2.4 inches.
YAMATAKE EST0240Z05WBX00
Resolution: 240×320 pixels.
Display color: 256 colors.
Display brightness: 200cd/m².
Display contrast ratio: 150:1.
Touch screen type: resistive touch screen.
Touch screen input method: finger or stylus.
CPU: 32-bit ARM Cortex-M3 processor.
Memory: 4MB Flash and 8MB RAM.
Communication interface: RS-485 and RS-232 serial communication interface.
Power input: 24V DC.
YAMATAKE EST0240Z05WBX00
Power consumption: 2W.
Operating temperature: 0℃~50℃.
Storage temperature: -20℃~60℃.
Humidity range: 10%~90%RH (non-condensing).
Vibration resistance: 10~55Hz, 0.75mm in both directions for 10min.
Translated with DeepL.com (free version)
YAMATAKE EST0240Z05WBX00

YAMATAKE EST0240Z05WBX00
