Woodward 9907-164 is a microprocessor-based control module produced by Woodward,which is mainly used to operate steam turbines as well as steam turbine generators and turbo expander modules.The following is a detailed introduction to it:

I.Product Overview

As part of the 505 and 505E series governor control unit,Woodward 9907-164 uses advanced digital microprocessor technology to achieve precise control of parameters such as fan speed and load.This control module is designed to meet the control requirements under various complex working conditions and provides rich control functions and data acquisition capabilities.

II.Main Features

High-precision control:Woodward 9907-164 uses digital microprocessor technology to achieve precise control of steam turbine parameters and improve system stability and reliability.

Rich control functions:The control module provides a variety of functions such as speed control,load control,compressor and turbine start and stop control,meeting the needs of different application scenarios.

Woodward 9907-164

Data acquisition and monitoring:Woodward 9907-164 can collect and monitor data related to turbine performance,such as speed,temperature,pressure,etc.,to ensure that the turbine operates within a safe and effective working range.

Communication interface:Supports a variety of communication interfaces,such as serial communication(RS-232,RS-485),Ethernet or fieldbus protocols(Profibus,Modbus),which facilitates data exchange and remote monitoring with other devices.

Self-diagnosis and fault detection:With self-diagnosis function,it can detect turbine faults and issue alarms,improving the reliability and safety of the system.

III.Hardware configuration

Input/output module:Woodward 9907-164 is equipped with 16 contact inputs(4 of which are dedicated and 12 are programmable)and 6 programmable current inputs from 4 to 20 mA,which meets the access requirements of different signals.

Operator control panel:The operator control panel on the front of the device can display two lines of text,24 characters per line,for controlling and changing menu-driven software.

Dimensions and Weight:The control module measures 14 inches wide,11 inches high,and 4 inches deep,with a moderate weight for easy installation and maintenance.

4.Software Configuration

The Woodward 9907-164 offers two human machine interface(HMI)software packages:OpView™and 505View.Both packages are self-configuring and require no on-site engineering,as they automatically configure the screen to match the control’s programming application.Here are the key features of the two packages:

OpView™:

Industrialized NEMA 4 touch screen hardware package bundled with Woodward-developed software.

Automatic screen generation based on control configuration.

Real-time trending capabilities.

Logging capabilities for event status.

Woodward 9907-164

505View:

Unbound Intellution-based software package that runs on a PC(optional hardware purchase).

Automatic screen generation,real-time and historical trending capabilities,logging and history capabilities for event status.

Remote access capabilities(only available in 505View).

Alarm/trip status indication and alarm/trip log with time stamp.

5.Application Scenarios

Woodward 9907-164 is widely used in situations where precise control of steam turbine parameters is required,such as power plants,chemical plants,steel plants,etc.By precisely controlling the speed and load of the steam turbine,energy utilization can be optimized,production efficiency can be improved,and operating costs can be reduced.

The company mainly imports PLC modules,programmable controllers,servo control systems and DCS spare parts,such as:ABB,AB(Rockwell),GE(General Electric),Bentley,Honeywell Er),Emerson.),Motorola,Invensys,Westinghouse,etc.The company has established close cooperative relations with many world-renowned PLC and DCS product maintenance service providers.We can purchase goods directly from abroad and provide equipment and spare parts from different countries and manufacturers.

We supply goods directly from abroad,without intermediaries,reducing the cost of use.

There is really no medium that can make a difference!!

Shenzhen Changxin Automation-sufficient supply,large spot quantity,guaranteed quality,you can buy with confidence and use with peace of mind~!

If you have any defects or needs for imported PLC and DCS spare parts,please contact our team,we will help you find reliable and high-quality products super quickly,while shortening delivery time to ensure that your equipment can operate normally in the right environment.Just in time.

Professionally provide:PLC programmable control system,distributed control system(DCS),safety instrument system(SIS),ESD system,vibration monitoring system,turbo compressor unit control system(CCS)and other PLC modules,various industrial control systems,system modules,CPU,IO module,DO module,AI module,DI module,network communication module,Ethernet module,motion controller,analog input module,analog output module,digital input module,digital output module,module redundancy,power module,relay output unit,relay input unit,processor unit.

Products are widely used in:electricity,petroleum,mine hoisting,ports,heating,gas,water supply,sewage treatment,metallurgy,papermaking,textile,chemical industry,water conservancy and other modern industrial fields!
