Description
Product Description
The V23818-M305-B57 INFINEON fiber optic transceiver is a high-performance optical module designed to achieve efficient and reliable communication.It can transmit and receive optical signals over long distances in fiber optic networks.
Features
•Small pluggable transceiver
Fully compliant with SFP MSA(1)
Advanced release mechanism-easy to access,even in abdominal to abdominal applications-easy to grip and approach-no need for tools-color coded release mechanism MM:black coded SM:blue coded
Excellent EMI performance
RJ-45 LC™Connector system
Single power supply(3.3 V)
Typical 415 mW ultra-low power consumption
Automatic data rate negotiation between 1.0625 and 2.125 GBd
Small size,suitable for high channel density
UL-94 V-0 certification
ESD level 1,compliant with MIL-STD 883D method 3015.7
•Compliant with FCC(Class B)and EN 55022•Suitable for distances up to 700 meters(50µm fiber)
•Complies with laser safety level 1 of the US Food and Drug Administration and the International Electrotechnical Commission
•AC/AC coupling compliant with SFP MSA
Suggestion:Infineon Cage integrated design V23818-S5-N1,suitable for press fit and/or weldable
Operating box temperature:-10°C to 85°C
The V23818-M305-B57 INFINEON fiber optic transceiver is a reliable and efficient solution to meet the needs of optical communication.It provides excellent performance and compatibility with various network devices.
The V23818-M305-B57 INFINEON fiber channel transceiver is part of the Infineon Small Form Factor transceiver series,based on Physical Media Dependent(PMD)sublayer and baseband medium,type(short wavelength),fiber channel FC PI 200-M5-SN-I,200-M6-SN-IFC-PI 100-M5-SN-I,100-M6-SN-IF C-PH2 100-M5-SN-I,FC-PH2 100-M6-SN-I.The appropriate fiber optic cable is 62.5µm or 50µm multimode fiber with LC™connector
The V23818-M305-B57 INFINEON fiber channel transceiver is a single unit consisting of a transmitter,receiver,and LC™container
This transceiver supports LC™The concept of connector.It is compatible with the RJ-45 backplane,suitable for high-end data communication and telecommunications applications,while providing the advantages of fiber optic technology.
The V23818-M305-B57 INFINEON fiber channel transceiver is designed specifically for low-cost SAN,LAN,WAN,and FibreChannel applications.
The V23818-M305-B57 INFINEON fiber channel transceiver operates on a single power supply(+3.3 V)at a frequency of 1.0625 GBd/2.125 GBd.Fully differential data input and output compatible with PECL and LVPECL
Application field
The V23818-M305-B57 INFINEON fiber channel transceiver can be used as a network device interface in mainframes,workstations,servers,and storage devices,as well as various network devices such as bridges,routers,hubs,and local and wide area switches.
