TEWS TPMC815-11 ARCNET Interface Module

Description

TEWS TPMC815-11 ARCNET Interface Module

Product Overview

TEWS TPMC815-11 is a standard single width 32-bit PMC module with a complete ARCNET interface using the controller COM20020.It is commonly used in industrial automation,building automation,and automotive applications,providing reliable and high-speed data transmission.TEWS is a well-known manufacturer of industrial automation products,known for their high performance,high reliability,and ease of use.The TPMC815-11 ARCNET interface module adopts a compact and durable design,which can withstand harsh environmental conditions and has multiple functions,making it an ideal choice for various applications.

TEWS TPMC815-11

Product parameters

Model:TPMC815-11

Interface type:ARCNET

Interface speed:2.5 Mbps

Node address:configurable

Bus topology:star,bus,or ring

Power supply voltage:5 V DC

Power consumption:maximum 5 W

Working temperature range:-40°C to 85°C

Storage temperature range:-55°C to 125°C

Humidity:5%to 95%(non condensing)

Protection level:IP67

Dimensions:114 mm x 75 mm x 25 mm

Weight:0.2 kg

Product specifications

Isolation voltage:250 V RMS

Common mode suppression:50 dB

TEWS TPMC815-11

Series

TPMC815-11 belongs to the TPMC800 series PMC module.This series of modules has the following characteristics:

High performance

High reliability

Usability

Features

The TPMC815-11 ARCNET interface module has the following features:

Supports standard ARCNET protocol

Configurable node addresses

Supports star,bus,and ring bus topologies

High speed 2.5 Mbps data transfer rate

250 V RMS isolation voltage

50 dB common mode suppression

Durable and sturdy design that can withstand harsh environmental conditions

Easy to install and maintain

Function

The function of the TEWS TPMC815-11 ARCNET interface module is to provide reliable and high-speed data transmission in industrial automation,building automation,and automotive applications.It can help users easily connect ARCNET devices to the control system.

TEWS TPMC815-11

Purpose

The TEWS TPMC815-11 ARCNET interface module can be used for various applications,including:

Industrial control system:Connect sensors,actuators,and other equipment to monitor and control the production process.

Building control system:connecting lighting,air conditioning,safety,and other building equipment.

Automotive applications:Connect engine control units,transmission control units,and other automotive equipment.

Application field

The TEWS TPMC815-11 ARCNET interface module can be applied in the following fields:

Manufacturing industry

Energy

Public utilities

Transportation

Architecture
