SCXI-1193 National Instruments

Description

• Product Name: SCXI-1193

• Product Description:

• The SCXI-1193 is a high-density, 32-channel RF multiplexer switch module from National Instruments. It can be configured as an unterminated multiplexer, an externally terminated multiplexer, or a sparsely matrix of various sizes. Each configuration can handle signal frequencies ranging from DC to over 500 MHz. The module features a slot and utilizes high-density push-fit MCX connectors for discrete yet manageable wiring. It cannot route signals to high-voltage analog buses. The SCXI-1193 is intended for integrating high-frequency equipment, including the PXI-5404 frequency generator and the PXI-5112 high-speed digitizer.

• Product Parameters:

  •

    SCXI-1193 National Instruments

• 32 channels
  DC to 500 MHz signal frequencies
  High-density push-fit MCX connectors
  Configurable as unterminated, externally terminated, or sparse matrix
  Not compatible with high-voltage analog buses

• Specification:

  •

    SCXI-1193 National Instruments

• Module dimensions (H x W x D): Dependent on specific configuration and National Instruments’ documentation.
  Weight: Dependent on specific configuration and National Instruments’ documentation.
  Operating temperature: Dependent on specific configuration and National Instruments’ documentation.
  Electrical specifications: Dependent on specific configuration and National Instruments’ documentation.
  Mechanical specifications: Dependent on specific configuration and National Instruments’ documentation.
  Warranty: Refer to National Instruments’ warranty policy.
•
