RELIANCE ELECTRIC S-D4007

Description

• Product Name: RELIANCE ELECTRIC S-D4007
• Product Description:
• The RELIANCE ELECTRIC S-D4007 is a high-performance industrial switch designed for use in demanding applications. It offers a robust and dependable switching solution, providing users with a reliable means of controlling various types of equipment and systems. The S-D4007 switch is built to withstand harsh environmental conditions, making it suitable for a wide range of industrial settings. It features a compact design, making it easy to install in tight spaces. The switch provides a choice of rocker or pushbutton operation, allowing for convenient and intuitive control.
• Product Parameters:
• Switch Type: Single-Pole, Double-Throw (SPDT)
  Actuator: Rocker or Pushbutton
  Contact Material: Silver-Tungsten Alloy
  Contact Resistance: ≤ 50 mΩ (typical)
  Contact Capacity: 10A @ 250V AC or 30A @ 30V DC
  Operating Temperature Range: -25°C to +85°C (-13°F to +185°F)
  Enclosure: IP67 Rated for Dust and Water Ingress Protection
  Mounting: Wall or DIN-Rail Mounting
  Weight: Approx. 120g (4.23 oz)
• Specification:
• Switching Performance:
  Switching Voltage: ≤ 30V DC or ≤ 250V AC
  Switching Current: ≤ 30A (peak)
  Switching Cycles: ≥ 100,000 cycles
  Electrical Life:
  Contacts: ≥ 50,000 operations (typical)
  Actuator: ≥ 50,000 operations (typical)
  Environmental Considerations:
  Operating Humidity Range: 5% to 95% non-condensing
  Storage Temperature Range: -40°C to +85°C (-40°F to +185°F)
  Mechanical Specifications:
  Mounting Options: Wall or DIN-Rail Mounting
  Actuator Force: ≤ 1.5N (pushbutton) ≤ 3N (rocker)
  Actuator Travel: ≤ 12mm (pushbutton) ≤ 2mm (rocker)
•
