Description
PR6423000-101-CN
The PR6423000-101-CN is an eddy current sensor designed for critical turbomachinery applications. Here are the details:
Product Parameters:
- Measuring Range: Linear Measurement Range 2 mm (80 mils)
- Initial Air Gap: 0.5 mm (20 mils)
- Incremental Scale Factor (ISF): 8 V/mm (203.2 mV/mil) ± 5% at temperature range 0 to 45°C (+32 to +113°F)
- Deviation from Best Fit Straight Line (DSL): ±0.025 mm (±1 mil) at temperature range 0 to 45°C (+32 to +113°F)
- Minimum Shaft Diameter: 25 mm (0.79″)
- Material: Sensor Tip (PEEK Polyether Ether Ketone), Case (Stainless Steel), Cable (PTFE Polytetrafluoroethylene), Connector (Brass, nickel-plated)
- Protection Class: IP66, IEC 60529
- Operating Temperature Range: Sensor incl. 1m Cable: -35 to +200°C (-31 to 392°F), Cable & Connector: -35 to +150°C (-31 to 302°F)
- Weight: Approx. 100 grams (3.53 oz) with 1m Cable
Product Specifications:
- The PR6423 is part of the EPRO series of sensors.
- It is a non-contact sensor designed for measuring radial and axial shaft dynamic displacement, position, eccentricity, and speed.
- It is suitable for use in harsh environments with a wide operating temperature range.
Series:
- EPRO Series of sensors, known for their reliability and precision in industrial applications.
Features:
- Non-contact measurement for high reliability.
- Measures a range of dynamic parameters critical for turbomachinery.
- Designed to operate in high-temperature environments.
- Protection against environmental factors is provided by its IP66 rating.
Role and Weight: The PR6423000-101-CN plays a critical role in monitoring the operational health of turbomachinery by providing accurate measurements of various parameters. Its weight, as mentioned, is approximately 100 grams with a 1-meter cable.
Application Fields:
- Industrial automation: Used in a variety of industrial settings where the monitoring of turbomachinery is required.
- Power generation: Useful in steam, gas, and hydro turbines for monitoring shaft displacement and vibration.
- Oil and gas: For compressors, pumps, and other critical equipment where reliability and safety are paramount.
- Other industries where precise measurement of shaft movement and position is necessary for the prevention of machinery failure and maintenance of process integrity.
