PR6423/000-000

Description

• Product Name PR6423/000-000

• Product Description

• The PR6423/000-000 is a high performance vibration sensor manufactured by EPRO in Germany. It is designed for use in a variety of industrial applications, including monitoring rotating machinery such as turbines, pumps and motors.

• Product Parameters:

  •

    PR6423/000-000

• Frequency Response: DC to 10 KHz (-3 dB).
  Probe diameter 8 mm.
  Sensitivity: 8 V/mm.
  Linear range: 2000 um.
  Linearity: ±0.75%.
  Minimum measurable surface: φ20 mm.
  *Ripple: ≤20 mV.
  *Temperature drift: ≤0.5%.
  *Output impedance: ≤500 Ω.
  *Insulation resistance: >25 MΩ.
  *Grounding: Floating ground.
  *Electromagnetic compatibility: CE compliant.
  *Outlet mode: Integral cable outlet.
  *Lead length: up to 300 meters from sensor to monitor or transmitter, frequency attenuation when length increases.
  *Operating temperature: -10°C to +85°C.

• Specification:

  •

    PR6423/000-000

• PR6423/000-000 Suitable for use in harsh industrial environments, PR6423/000-000 is the best choice for monitoring machines in these conditions.
  Sensitivity up to 8 V/mm ensures accurate measurement of vibration levels.
  The sensor has a linearity of ±0.75% for accurate and reliable readings.
•

  PR6423/000-000
