Product Description: NI SCXI-1520 is a control module that is typically used in NI’s SCXI (Signal Conditioning eXtensions for Instrumentation) modular measurement and control systems to condition signals and acquire data. This module is often employed to manage and control signals routed to external modules within the SCXI system.
Product Description: NI SCXI-1520 is a control module that is typically used in NI’s SCXI (Signal Conditioning eXtensions for Instrumentation) modular measurement and control systems to condition signals and acquire data. This module is often employed to manage and control signals routed to external modules within the SCXI system.
Product Parameters:
Physical Characteristics:
Width: 22.9 mm
Height: 216.0 mm
Depth: 290.0 mm
Weight: 0.91 kg
I/O Characteristics:
8-Channel Strain/Bridge Input Module
Measures strain, force, torque, and pressure sensors
Quasi-Bridge, Half-Bridge, and Full-Bridge Configurations
Software-selectable voltage excitation
Multiple low-pass filters
Over 40 input gain settings
Performance Characteristics:
Response Time: 10 ms
Switching Life: 5×10^7 operations
Operating Characteristics:
Power: 60 W Max
Voltage: 250 Vrms Max
Current: 2 A Max
Specification:
NI SCXI-1520 is a control module designed for SCXI systems.
It is used to manage and control signals within SCXI systems.
The module can be configured channel-by-channel to adapt to specific measurement needs.
It supports a variety of sensor types and configurations, including strain, force, torque, and pressure sensors.
The module features software-selectable voltage excitation, multiple low-pass filters, and over 40 input gain settings for flexible signal conditioning.
NI SCXI-1520 offers a fast response time and a high switching life for reliable performance in demanding applications.
