Description

SCXI-1141 182610D-01 is an industrial control card module produced by National Instruments(NI).The following is a detailed introduction to the module:

1.Product Overview

The SCXI-1141 182610D-01 module belongs to the SCXI(Signal Conditioning eXtensions for Instrumentation)modular data acquisition system and is an industrial control card dedicated to data acquisition and control.It is usually used in laboratory testing and industrial automation applications,providing signal conditioning and data acquisition functions.

2.Main Features

Data acquisition and control functions:

Supports multiple types of input and output signals,enabling real-time data acquisition and precise control.

High-speed data transmission:

With high-speed data transmission capabilities,it can quickly process and transmit large amounts of data.

Modular design:

Adopting modular design,it is easy to integrate and expand,and can be used with other SCXI modules to build a complete control system.

Programmable control:

Supports multiple programming languagesand development environments,making it convenient for users to configure,program and control.

High reliability and stability:

Using high-quality electrical and mechanical components,strict quality control and testing ensures stable and reliable operation under harsh environmental conditions.

Easy to maintain and debug:

Provide a wealth of debugging tools and functions to facilitate users to troubleshoot and optimize the system.

SCXI-1141 182610D-01

III.Detailed functions

Sensor interface:

Used to interface different types of sensors,such as temperature sensors,pressure sensors,displacement sensors,etc.,in order to obtain and process sensor output signals.

Programmable filter:

SCXI-1141 182610D-01 is also a programmable filter module,which is ideal for anti-aliasing applications.The combination of analog filters and switched capacitor filters provides 10,000 discrete software programmable cutoff frequencies for users to flexibly choose,while maintaining the low noise performance of traditional continuous-time active filters.Although all channels must set the same cutoff frequency,the signal of the low-pass filter of a certain channel can be bypassed by programming.

Industrial automation system:

In industrial environments,it is used to monitor and control various industrial processes and integrated into industrial automation systems for real-time data acquisition and control.

Laboratory Measurement:

Used for various measurements and experiments in scientific laboratories to support laboratory research projects,including physics,chemistry,biology and other fields.

Control System:

Can be used to build control systems,process sensor signals,and achieve feedback and control of the system.

Data Acquisition System:

As part of the data acquisition system,it is used to collect and condition signals from various sensors to support real-time monitoring and data recording.

Vibration and Acoustic Analysis:

Used for vibration and acoustic analysis applications to condition and analyze the output signals of vibration sensors and acoustic sensors.

Education and Training:

Used in teaching laboratories to help students learn the basic principles of data acquisition,signal processing and instrument control.

SCXI-1141 182610D-01

IV.Technical Specifications(Example)

Please note that the specific technical specifications may change due to product versions or manufacturer updates.Here are some examples of possible specifications:

Input range:Programmable settings(e.g.,±50 mV to±5 V)

Filter settings:8th order programmable filter(10 Hz to 25 kHz)

Maximum sampling rate:333 kS/s(arbitrary gain)

Gain:Programmable gain per channel

V.Installation and Configuration

The following items are required to install the SCXI-1141 module:SCXI-1141 module,SCXI chassis or PXI combination chassis,1/4-inch flat-blade screwdriver.The specific installation steps are as follows:

Double-click the”Measurement and Automation Explorer”icon on the desktop.

Click the”+”next to the device and interface icons to display a list of installed devices and interfaces.

Find the SCXI chassis in the list.Click the”+”sign next to the chassis description to display a list of modules in the chassis.

Right-click the SCXI-1141 module to be configured and select”Properties”.Click the”General”tab to configure.
