NI PXIe-5105

Description

NI PXIe-5105 is a high-performance digitizer suitable for various data acquisition and signal processing applications.The following is a detailed introduction to the product:

I.Product Overview

PXIe-5105 is a PXI(PCI extensions for Instrumentation)bus oscilloscope module produced by NI(National Instruments,National Instruments,USA),designed for high-speed,high-precision data acquisition.It provides 8 synchronous sampling channels,each with 12-bit vertical resolution and 60 MS/s(million samples per second)real-time sampling rate,and 60 MHz analog bandwidth.

II.Main Features

Multi-channel synchronous sampling:

PXIe-5105 provides 8 synchronous sampling channels,which can collect multiple signals at the same time,ensuring the timing consistency between data,which is particularly important for measurements that require precise time correlation.

High vertical resolution:

With 12-bit vertical resolution,it can finely quantize the input signal and capture more subtle signal changes.

High real-time sampling rate:

The real-time sampling rate reaches 60 MS/s,which can accurately capture fast-changing signals,such as high-frequency signals or short-time events.

NI PXIe-5105

Wide bandwidth:

With an analog bandwidth of 60 MHz,it can handle frequency components in a wide range,which is very beneficial for the acquisition of broadband signals.

Large-capacity storage:

The onboard memory is up to 512 MB,which can collect data for a long time without real-time processing or data transmission.

Modularity and scalability:

It can be used in combination with other PXIe-5105 digitizers to achieve high-channel count applications,providing great flexibility for large test systems or multi-point monitoring projects.

Multiple trigger modes:

The PXIe-5105 oscilloscope has multiple trigger modes,which can be flexibly set according to signal characteristics to meet the needs of different application scenarios.

Instrument driver:

Instrument drivers with data streaming and analysis functions are provided to facilitate users to process and analyze data.

NI PXIe-5105

III.Application fields

The PXIe-5105 digitizer is widely used in fields that require high-performance data acquisition and signal processing,such as:

Laboratory research:used for data acquisition and analysis in various scientific experiments and research.

Industrial Automation:In industrial automation systems,it is used to monitor and control various parameters in the production process.

Consumer Electronics:It is used for testing and verification of consumer electronic products.

Military/Aerospace:In the military and aerospace fields,it is used to test and monitor the performance of various devices and systems.

IV.Technical Specifications(Partial)

Number of channels:8 simultaneous sampling channels.

Vertical resolution:12 bits.

Real-time sampling rate:60 MS/s.

Analog bandwidth:60 MHz.

Onboard memory:512 MB.

Bus type:PXI Express.

Input impedance:1 MΩ(optional 50 ohms).

Input voltage range:-15 V to 15 V.
