NI-9505

Description

NI-9505 is a specific product provided by the manufacturer,usually related to industrial automation,embedded systems or data acquisition.The following is a detailed introduction to NI-9505:

I.Product Overview

NI-9505 is a C series drive motion module that integrates advanced motion control functions and is suitable for various industrial automation and control systems.The module adopts a compact design and is easy to integrate into existing systems while providing high performance and reliability.

NI-9505

II.Main Features

Single-axis control:

NI-9505 is a single-axis module that can be used to control a single motion axis.

Multiple motor support:

The module supports the drive of bipolar or unipolar hybrid stepper motors and three-phase servo brushless motors.

Seamless integration:

NI-9505 provides seamless integration with proven measurement and control platforms,allowing users to quickly build and deploy motion control systems.

Advanced PWM algorithm:

Advanced PWM algorithm is used to reduce torque fluctuations,minimize power loss,and smooth microstepping,improving the accuracy and stability of motion control.

Software Programmability:

Users can use software such as LabVIEW FPGA and NI SoftMotion for custom programming to achieve custom settings for parameters such as rate and current reduction.

CompactRIO Chassis Integration:

NI-9505 can be integrated into the CompactRIO chassis and used in combination with other modules to build a multi-axis motion controller with user-customizable I/O.

NI-9505

III.Application Fields

NI-9505 is widely used in fields that require high-precision and high-reliability motion control,including but not limited to:

Industrial Automation:

Used for precise position control and speed control on automated production lines.

Robotics:

In robotic systems,used to control the joint motion of the robot and the precise position of the end effector.

Semiconductor Manufacturing:

In the semiconductor manufacturing process,used to control the precise movement and positioning of wafer processing equipment.

Medical Equipment:

In medical equipment,used to control the high-precision motion of surgical robots,diagnostic equipment,etc.

4.Technical Specifications(reference)

Manufacturer:NI(National Instruments)

Model:NI-9505

Type:C Series Drive Motion Module

Supported Motor Type:Bipolar or Unipolar Hybrid Stepper Motor,Three-Phase Servo Brushless Motor

Number of Controlled Axes:Single Axis

Integrated Platform:CompactRIO

Programming Software:LabVIEW FPGA,NI SoftMotion
