NI-9505

Description

• The NI-9505 is a National Instruments C-Series motor drive module.
• Product Name: NI-9505
  Product Description.
• It is equipped with 3 differential or single-ended input lines and includes a complete encoder interface.The NI-9505 offers exceptional flexibility and customization, and is compatible with LabVIEW FPGA modules.It generates custom motor drive and actuator amplifiers. It generates customized motor drive and actuator amplifiers. The LabVIEW FPGA module generates a PWM signal and directs the signal to the NI 9505, which is compared to the expected current or torque. By increasing the PWM duty cycle, the current is increased and therefore the torque is increased.
• Product Parameters.
• The recommended PWM frequency is 20 kHz and may be as high as 40 kHz.The device has a recommended operating temperature range of -40 to 70°C and a storage temperature range of -40 to 85°C. The device can be used in a wide variety of applications, including industrial and commercial applications.
• Specification.
• The NI-9505 module allows quadrature encoder signals to pass through and the signals are processed in a LabVIEW FPGA module for position and velocity loops.SoftMotion offers more innovative motion control applications with position and velocity PID control and trajectory generation. It can also provide blade exclamation point and encoder applications.SoftMotion uses LabVIEW FPGA modules and LabVIEW real-time modules to implement this functionality.
•
