Description

MTL5053 MTL isolator/power supply 31.25kbit/s fieldbus

Product Description

MTL5053 is an isolator/power supply produced by MTL Instruments Ltd.,used to transport 31.25kbit/s on-site through hazardous areas at network boundaries.It provides power and communication lines for devices powered by signals.For a safety zone boundary length of one small MTL5053,it complies with Intrinsically Safe fieldbus requirements™Requirements for power supply type 133†(IS power supply).

This isolator/power supply has the following characteristics:

Complies with Intrinsically Safe on-site corridors™Power supply type 133†requirements

Provide power and communication lines for devices powered by signals

Supports a walking length of up to 1000 meters in a safe area

Internal terminal resistors can be used for short safety area corridors

3.Voice power input

Output current and voltage monitoring

Fault indication

MTL5053 MTL

Product parameters

Model:MTL5053

Entrance type:31.25kbit/s on-site exit

Safe area route length:maximum 1000 meters

Input voltage:24VDC or 48VDC

Output voltage:24V DC

Output current:maximum 1.2A

Consumption:Maximum 15W

Working temperature:-20°C to 60°C

Storage temperature:-40°C to 85°C

Humidity:5%to 95%(non condensing)

Protection level:IP67

Size:110mm x 70mm x 35mm

Weight:0.5 kilograms

MTL5053 MTL

Product specifications

Isolation voltage:250V effective value

Rated value of solid-state relay:2A 24VDC

Reverse current protection:maximum 1.5A

Output overvoltage protection:maximum 30 VDC

Output short-circuit protection:electronic current limiting

Series

MTL5053 belongs to the MTL5000 series isolator/power supply.This series of products has the following characteristics:

Meets various on-site standards

Provide safe isolation for various hazardous area applications

Durable and sturdy,suitable for use in statistical environments

MTL5053 MTL

Features

MTL5053 has the following characteristics:

Complies with Intrinsically Safe on-site corridors™Power supply type 133†requirements

Provide power and communication lines for devices powered by signals

Supports a walking length of up to 1000 meters in a safe area

Internal terminal resistors can be used for short safety area corridors

3.Voice power input

Output current and voltage monitoring

Fault indication

Function

The function of MTL5053 is to traverse hazardous areas in network zones at 31.25kbit/s on site,while providing safe isolation and power supply for equipment powered by signals.

Purpose

MTL5053 can be used for various hazardous area applications,including:

Oil and natural gas

Chemicals

Pharmaceutical

Food and Beverages

Water treatment

Application field

MTL5053 can evaluate the following areas:

Industrial automation

Process control

Discrete manufacturing
