MODHUB-16E CONTAMPORARY HUB

　　Product Description

　　MODHUB-16E Contemporary Hub is a high-quality device that allows you to connect multiple devices in one hub.It aims to provide seamless connectivity and enhance the convenience of various applications.

　　Features

　　Compatible with baseband 2.5 Mbps ARCNET network

　　Four slots support up to 16 ports

　　Single size shell:4 slots

　　Easy extension through EXP series plugin modules

　　Mix coaxial cables,twisted pair cables,and fiberglass cables in one hub

　　LED indicator lights can recognize network reconfiguration

　　Minimize hub jitter through precise delay line timing

　　Provide rack installation accessories

　　Watchdog timer to prevent hub locking

　　Digital control hub unlock delay

　　Universal voltage power supply

　　When running at 2.5 Mbps,it can be used in conjunction with all Science and Technology Control Network Interface Modules(NIMs)

　　Product details

　　The MOD HUB series modular active hubs are flexible enough to use star or bus topologies for wiring ARCNET networks.The unit can connect the bus topology by connecting the hub to one end of each bus segment.

　　These 4-slot hubs use low-power,low heat CMOS components for worry free operation;High efficiency LED lights;Special cooling systems inherent in the design;And the network diagnostic function using LED indicator lights.

　　LED monitors the correct hub timing and power status.Additional LED report network reconfiguration.

　　Provide different shell styles to meet any requirements.Using the rack installation kit,two 4-slot cabinets can be installed in standard 19 inch(48.3 cm)racks that require 7 inches(17.8 cm)of vertical rack space.Alternatively,the MODHUB-16F flange device allows for wall installation.

　　There are multiple expansion modules in the EXP series,each supporting two or four ports.You can mix and match coaxial cables,twisted pair cables,and fiberglass cables in just one hub.

　　Two combination expansion modules mix two types of wiring into one module.Ports can be easily added on-site using removable EXP expansion modules.

　　As for regulatory compliance,all models have passed UL 60950 certification and C-UL certification(CSA 22.2 No 60950)to ensure the security of information technology equipment.

　　Universal power supply can adapt to global voltage and frequency.IEC connectors allow the use of specific country/region power requirements.

　　Application field

　　The MODHUB-16E CONTAMPORARY hub is widely used in various industrial automation fields,such as power,chemical,metallurgical,pharmaceutical,food processing,and other industries.
