Description
Product description
IS200EGPAG1BCA GE exciter gate pulse amplifier board is used to amplify and control the pulse signal used to excite the generator field winding.
trait
Provides amplification of the pulse signal
Make sure the exciter door works properly
The IS200EGPAG1BCA is a pulse amplifier board specially designed for exciter gates.It amplifies the pulse signal to ensure that the gate in the exciter system works properly.
The GE EX2100 IS200EGPAG1BCA exciter gate pulse amplifier board is used to connect the control to the power bridge in the control system.It is responsible for connecting current conduction feedback,temperature monitoring and bridging airflow.
The gate pulse amplifier board number IS200EGPAG1BCA is located in the power conversion cabinet and can be connected to the power conversion module.This module is one of the boards marked below the bridge and the protection board/module,and although the board can operate independently,it usually requires power from one of the EPDM modules.
The IS200EGPAG1BCA board receives feedback from two thermal switches mounted on the SCR radiator.These switches trigger and disconnect at alarm and trip levels and are directly connected to the IS200EGPAG1BCA.The temperature the switch must reach before triggering is a trip level of 190°F and an alarm level of 170°F.If only one switch is open,an overheating alarm about the bridge has occurred,if both switches are open,it indicates that a trip and a fault has occurred,and the switches can be opened separately or together.
The IS200EGPAG1BCA board has five jumpers that allow the user to select the desired application-specific configuration and easily adjust the jumper configuration before installation.
Application field
IS200EGPAG1BCA GE exciter gate pulse amplifier board is mainly used in the field of excitation control of power plants and power systems,such as thermal power plants,hydropower stations,etc.
