IC693CPU372-AE GE TCP I/P Ethernet communication interface

Description

Product description

IC693CPU372-AE is an Ethernet communication interface module that can implement TCP/IP communication.

trait

Support TCP/IP communication protocol

Provides Ethernet connections for GE devices

Allows reliable and efficient data transfer

The IC693CPU372-AE is a high-performance communication interface module designed for seamless integration with GE automation systems.It supports TCP/IP communication,allowing devices to exchange data over Ethernet.With its powerful features and reliable performance,the module is ideal for a variety of applications in industrial environments.

The IC693CPU372 is a 90-30 series component manufactured by GE Fanuc.This is a single slot modular CPU.It is powered by an AMD SC520 processor with a 133MHz CPU and a maximum user program memory of 240Kbytes.It supports 2048 discrete inputs,2048 discrete outputs,32,640(Max)analog input words,and 32,640(Max)analog output words.It has two(2)built-in Ethernet interfaces,supports 10/100 mbps transfer speeds,and supports Industrial Ethernet and Modbus TCP/IP.

IC693CPU372 is a TCP I/P Ethernet communication interface.The module is mainly used to realize Ethernet communication,supporting Modbus TCP Server/Client,industrial Ethernet and other system protocols.The module can be used to perform regular data exchange using Ethernet Global Data(EGD),SRTP,and SRTP clients.

The IC693CPU372 supports full PLC programming and configuration services.It is equipped with dual Ethernet ports that share the same IP address and act as an internal Ethernet switch,allowing daisy-chain connectivity for network connectivity and device level ring(DLR)topology implementation.Each port supports network automatic awareness,eliminating the need to assign modules based on the speed of the existing network.

The IC693CPU372 comes with a dedicated processor with a clock speed of 133 MHz.For configuration,the built-in network server allows remote connection to a configuration station that can be used to introduce simple configuration to the module as well as module monitoring.For programming programmable Logic controller(PLC)functions,the IC693CPU372 is configured using the Machine Edition of PLC Logic Developer in the Proficy Machine Edition package.

The IC693CPU372 supports 2048 discrete inputs,2048 discrete outputs,128-32,640 analog input words,and 128-32,640 analog output words(Max.)for a total user memory of 240 KB.The internal memory is of the random access memory(RAM)type and is powered by a battery.Optional non-volatile memory or flash memory can be added to provide memory that does not require battery power to retain the contents of the memory.

The IC693CPU372 module is designed and manufactured by GE Fanuc.The industrial communication module is designed to communicate over industrial Ethernet operating over the TCP/IP protocol.The unit is compatible with GE PLC equipment from the 90-30 series or VersaMax series,or with PLC equipment from a part of PACSystems.The IC693CPU372 module has an integrated interface for Ethernet communication and can be used with hosts that have all the necessary software tools installed.The Ethernet interface supports up to 3 different 90-30 series modules that can provide additional functionality.The backplane of the 90-30 series programmable logic controllers can use combination modules to improve the performance of the entire system.

The IC693CPU372 communication module has 2048 input/output points and provides 240KB of storage capacity.Like most similar components in the series,the module has a type 80386EX processor for 32-bit systems.The device supports communication over popular networks such as 100BaseTX IEEE 802.3 and 10BaseT networks.For this purpose,the device includes two shielded Ethernet ports with automatic sensing functions.The unit has a pair of Ethernet connectors,a station manager function connector,LED status indicators,a master switch,and a restart button.The IC693CPU372 module supports floating point math,duplex mode,easy configuration and programming,and SRTP server options.The IC693CPU372 module has a processor operating at 133 MHZ and supports RAM or flash memory for storage.The device runs on a backup battery and requires 7.4 watts of 5 volts direct current.

Application field

IC693CPU372-AE GE TCP I/P Ethernet communication interface used in industrial automation systems for communication between devices over Ethernet.
