The IB ST 24, produced by an “Other Brands” manufacturer, is a counter module designed for pulse counting, frequency measurement, time measurement, and generation of square wave pulses.
The IB ST 24, produced by an “Other Brands” manufacturer, is a counter module designed for pulse counting, frequency measurement, time measurement, and generation of square wave pulses. This module offers four independently operable channels, each with a 16-bit resolution. It can be easily cascaded by connecting multiple counters together. Each channel has an output that can be configured based on events. Simple applications can utilize a single device. The module supports both screw and spring connections.
Product Parameters:
Counting Capability: The module can count pulses and measure frequency and time.
Channels: The module has four independent channels.
Resolution: Each channel offers a 16-bit resolution.
Cascading: Multiple counters can be cascaded for expanded functionality.
Outputs: Each channel has an output that can be configured based on events.
Connections: The module supports both screw and spring connections.
Product Specification:
Dimensions: Width – 118 mm, Height – 117 mm, Depth – 116 mm.
Connection Type: ST local bus connector.
Transmission Speed: 500 kBit/s.
Input Voltage: 5 V DC or 24 V DC.
Input Frequency: Up to 90 kHz (maximum 300 kHz).
Input Current: 11 mA (typical at 24 V DC input) or 8 mA (typical at 5 V DC input).
Output Voltage: US – 0.5 V DC.
Output Current: 500 mA per output (up to 300 Hz) or 250 mA per output (up to 10 kHz).
Please note that without specific information from the “Other Brands” manufacturer, the above product description, parameters, and specifications are general and may not accurately reflect the actual details of the IB ST 24 product. It is essential to consult the manufacturer’s official documentation or contact their technical support team for accurate and detailed information.
