HIMA F3237 984323702

Description

HIMA F3237 984323702

HIMA F3237 984323702 is a high-performance industrial module widely used in a variety of safety-critical production processes and automation systems. Below are the detailed parameters, specifications, series, dimensions, features, weight and application areas of this product:

Product Parameters & Specifications:

– **Model Number**: HIMA F3237 984323702
– **Part Number**: 984323702
– **Compatibility**: Compatible with HIMA control system.
– **Input Voltage**: 24V DC.
– **Output Voltage**: 24V DC.
– **Maximum load current**: 2A.
– **Operating temperature range**: -40℃ to +70℃ or -20℃ to +60℃.
– **Communication Interface**: Support Ethernet, RS485, PROFIBUS, PROFINET, etc.

Dimensions & Weight:

– **DIMENSIONS**: Dimensions vary depending on the source. For example: 140 mm × 200 mm × 70 mm; 120 mm × 80 mm × 35 mm; 71 mm × 99 mm.
– **Weight**: approx. 1.5 kg.

### Features:
– **Protection rating**: IP20.
– **Safety level**: SIL3.
– **Number of Channels**: Multiple input channels are provided, the exact number may vary from version to version, e.g. 8 or 16 channels.
– **Wire impedance**: ≤50 Ohm (according to DIN 19234).
– **Wire length**: ≤ 1000 m (wire diameter 0.5 mm²).

Areas of application:

The modules are widely used in the following areas:
– Industrial automation and control systems.
– Safety-critical production processes such as emergency stop systems (SIS), fire and gas protection systems (F&G), LNG protection systems, high pressure protection systems (HIPPS), etc.
– Automotive manufacturing, pharmaceutical, petroleum and chemical industries.

This information provides a comprehensive understanding of the technical characteristics of the HIMA F3237 984323702 module and its wide range of applications in industrial automation.
