Description

IC754VSI12VTD is a control display panel or related equipment produced by GE(General Electric).The following is a detailed introduction to it:

1.Basic properties

Brand:GE(General Electric)

Model:IC754VSI12VTD

2.Technical indicators

Measurement parameters and range:

Test voltage:kV(specific range not detailed)

Third harmonic voltage:kV(specific range not detailed)

Full current(peak):0~20mA

Third harmonic current:0~20mA

Resistive current(peak):0~20mA

Resistive current peak:0~20mA

Capacitive current(peak):0~20mA

Lightning arrester power consumption:0~8W

IC754VSI12VTD

Measurement error:

Test voltage:±5%

Full current:±2%

Resistive current:±5%

Capacitive current:±5%

Lightning arrester power consumption:±5%

Input signal:

Voltage signal(PT low voltage measurement):AC 5~400V

Current signal:AC 0~20mA

Working power supply:AC 220V±10%50Hz

III.Product features

Large-screen LCD display:It adopts a large-screen LCD display to provide a clear and intuitive display interface.

Full-Chinese menu operation:It supports full-Chinese menu operation,which is easy to use and easy to get started.

High-precision sampling and processing circuit:It adopts high-precision sampling and processing circuit to ensure the accuracy and reliability of the measured data.

Advanced Fourier harmonic analysis technology:It applies advanced Fourier harmonic analysis technology to conduct in-depth analysis of the measured data and improve the accuracy and efficiency of data processing.

Unique high-speed magnetic isolation digital sensor:It adopts a unique high-speed magnetic isolation digital sensor to directly collect the input voltage and current signals to ensure the reliability and security of the data.

No-voltage method:It supports no-voltage measurement,and does not need to take the PT secondary voltage signal.The voltage reference is found by software calculation.

Electric field induction method:The electric field induction method can be used instead of the PT secondary wiring to simplify the measurement process.

Versatility:It has the functions of resistive current fundamental peak output and side phase correction to meet various measurement needs.

IC754VSI12VTD

IV.Application Scenarios

IC754VSI12VTD is suitable for various occasions that require high-precision measurement and display,such as the power industry,industrial automation control systems,etc.It can be used to monitor and control the operating status of power equipment to ensure the safe and stable operation of the power system.
