GE-IC698PSA100-1-1

Description

The GE-IC698PSA100-1-1 is an Ethernet interface module model IC698PSA100-1-1 from General Electric.
It features high-performance Ethernet functionality that can be seamlessly integrated with other devices to improve system reliability and stability.
The module has two Ethernet communication ports that support 10/100 Mbps communication rate with auto-detection function. In addition, it has a serial communication port that supports a transmission speed of 1200-115,200 bps. The module supports TCP/IP communication services using SRTP, SRTP client, Modbus/TCP server and MODBUS/TCP client. In addition, it supports time synchronization with SNTP time servers on Ethernet networks. The module is equipped with various LED indicators that provide an overview of the current status of the module.

The module is characterized by:
Provides +5VDC, +12VDC and -12VDC power supplies as well as logic level sequence signals for the modules on the backplane.
Mounted in slot 0 of the main frame.
The power supply output may lose one AC input line cycle, but virtually no output power is lost.
Overcurrent, overheat, and overvoltage fault conditions are also protected.
Allows 100 watts total output power at ambient temperatures from 0 to 60°C with no forced air cooling.
Equipped with LED indicators to alert the user to field and output status.
