GE IC693ALG223D

Description

IC693ALG223D is a product of GE(General Electric).The specific information is as follows:

1.Product Overview

IC693ALG223D is a PACSystems Series 90-30 RX3i analog current input module.It provides 16 channels for receiving and collecting analog current signals.

2.Product Features

Channel Configuration:The 16 channels of IC693ALG223D are independent single-ended channels and can be configured as one of the following three ranges:4 to 20mA,0 to 20mA,or 4 to 20mA enhanced.

Alarm Function:In each range,high and low alarms can be set.In the enhanced range,the module can also set a low alarm limit to detect open circuit faults in 4 to 20mA applications,and the user can also set a high alarm.

GE IC693ALG223D

Status Reporting:The module is able to report its status,including power supply conditions,and send this information to the CPU.

Compatibility:IC693ALG223D can be used in any I/O slot in RX3i or Series 90-30 systems that provides a serial connector.

Power Requirements:The module requires 120mA of current from the+5VDC bus on the controller backplane,and also requires a user-supplied+24VDC power supply to supply more than 65mA of current.

Update Rate and Isolation:The standard update rate is 6ms,with 250VAC continuous or 1500VAC(for 1 minute)isolation.

LED Indicator:Equipped with LED status indicators,showing ON,OFF and FAIL status,to help users operate and troubleshoot.

GE IC693ALG223D

III.Product Applications

As part of GE Electric DCS(Distributed Control System)/PLC(Programmable Logic Controller)industrial control system,IC693ALG223D module is widely used in various industrial automation fields,including rail transit,etc.,for receiving and processing analog current signals from sensors,and passing this information to the CPU of the PLC or DCS system for further processing and control.
