Description

DS200FGPAG1AHD is a high-performance gate pulse amplifier board produced by General Electric(GE,now Emerson).The following is a detailed introduction to it:

I.Product Overview

DS200FGPAG1AHD gate pulse amplifier board is an electronic component that mainly works based on gate pulse power supply.It is designed for applications that require accurate and reliable gate pulse amplification and can enhance the strength and quality of gate pulse signals.

II.Working Principle

In the gate pulse power supply,the gate DC voltage is converted into a pulse voltage by the switch control circuit and then applied to the amplifier gate.By turning the gate voltage on and off,the working state of the amplifier is periodically switched between on and off.When the gate voltage value is the typical static operating point voltage,the amplifier works;when the gate voltage is the pinch-off voltage,the amplifier is turned off.

DS200FGPAG1AHD

III.Product Features

High-precision amplification:The board can accurately amplify pulse signals to meet the strict requirements of signal strength and quality in industrial systems.

Wide input voltage range:The DS200FGPAG1AHD supports an input voltage range of 115230VAC,and the allowable range is extended to 90260VAC,which enables it to work stably in different power supply environments.

Wide operating frequency range:Its operating frequency range is 5060Hz,and the allowable range is extended to 4763Hz,which can adapt to a variety of different industrial application scenarios.

Polarity protection:The board does not require polarity protection when powered by AC,which simplifies the installation and configuration process.

Voltage/frequency abnormal range protection:When the operating voltage is lower than the normal range,the board is designed to ensure that the module will not be damaged,improving the reliability and stability of the equipment.

Power supply fault protection:In the event of a power supply failure,after more than 20 milliseconds,the board will automatically switch to safe mode to protect the system from potential damage.

Insurance measures:DS200FGPAG1AHD uses a glass fuse with a rating of 2.5AT,which is connected to the input end to provide additional safety for the device.

DS200FGPAG1AHD

IV.Application Fields

The DS200FGPAG1AHD gate pulse amplifier board is suitable for industrial systems that require precise control and monitoring,such as automated production lines,mechanical equipment,sensor networks,etc.By providing stable and reliable gate pulse amplification,it can ensure efficient operation and precise control of industrial systems.

Video amplifier:In the video amplifier,the gate pulse amplifier is used to ensure that the output of R/G/B can automatically and sequentially switch between the pulses that generate the measured light spots and the pulses that provide the reference light spots,turning on only one output of the light spots that need to be displayed and turning off the other output of the light spots that do not need to be displayed.

Pulse radar:In pulse radar applications,the high power amplifier(HPA)needs to be turned on/off quickly during the transition from transmit to receive operation.The gate pulse circuit can efficiently control the power amplifier and realize its high-speed switching,thereby improving the performance of the pulse radar.
