　　DS200FCGDH1B GE LCI Control and Door Control Board

　　Series:

　　GE LCI 200 series

　　Function:

　　As the core component of the LCI 200 system,it is used to control the operation of the LCI 200 system

　　Usage:

　　Industrial automation control system

　　Power system

　　Petrochemical industry

　　Metallurgy

　　Features:

　　High performance:based on Intel®Core™I7-6820EQ processor

　　High reliability:adopting redundant design

　　Easy to maintain:supports hot swapping

　　Product Description:

　　DS200FCGDH1B is Gate Allocation and Status Card(FCGD).This card was developed by General Electric for its Mark V board series and can be installed in various GE branded drives.After installation,the card serves as the interface system for the six pulse phase controlled non reverse bridge.DSPC(Digital Signal Processing Card)forwards information to the board for decryption.This generates signals related to diagnostic information and system feedback.Then use the integrated VME backplane of the driver to send these feedback.

　　DS200FCGDH1B collects a large amount of data from the integrated DSPC of the driver.The signal received by the board is converted into a unit gating signal.All system bridge arms receive the unit gate signal and return the multiplexing unit status information to the card.The FCGD board also receives and scales feedback signals.Three FGPA boards send feedback signals through fiber optic connections on the board.The feedback included includes frequency,voltage,and circuit board status information.The integrated IMOK LED status indicator provides users with basic system status.

　　The DS200FCGDH1B GE LCI control and door control board adopts a modular design,which is easy to install.It has the following structure:

　　CPU module:includes processor,memory,and cache

　　I/O module:includes various I/O interfaces

　　Product parameters:

　　Processor:Intel®Core™I7-6820EQ

　　Main frequency:2.7 GHz

　　Memory:Up to 32 GB DDR4 ECC memory

　　Storage:Up to 256 GB solid-state drive

　　I/O interfaces:including 2 GbE interfaces,4 USB 3.0 interfaces,1 RS-232 interface,and 1 VGA interface

　　Product specifications:

　　Dimensions:233mm x 102mm x 41mm

　　Weight:1.2kg

　　Application field:

　　DS200FCGDH1B GE LCI control and gate control boards can be widely used in industrial automation control systems,power systems,petrochemical,metallurgical and other fields.

　　Here are some specific application examples:

　　In industrial automation control systems,used to control production lines,robots,and other equipment

　　In the power system,used to control power plants,substations,and distribution networks

　　In the petrochemical industry,it is used to control the production process of refineries and chemical plants

　　In the metallurgical industry,it is used to control the production process of steel plants
