Product Description:
The DR-120-24 is a DIN rail-mounted switching power supply that provides a constant output voltage of 24V with a maximum current of 5A. It is designed for use in a wide range of applications, including industrial automation, LED lighting, telecommunications, and security surveillance systems. The power supply features short-circuit, over-current, over-voltage, and over-temperature protection to ensure reliable and safe operation.
Product Parameters:
Output Voltage: 24V DC
Output Current: 5A
Input Voltage Range: 90-264VAC or 180-370VDC (selectable via switch)
Power Rating: 120W
Efficiency: Up to 84%
Operating Temperature: -10 to +60°C
Storage Temperature: -25 to +85°C
Dimensions: 100 x 65.5 x 125mm (W x H x D)
Weight: Approx. 350g
Product Specification:
DIN rail mountable for easy installation
Short-circuit, over-current, over-voltage, and over-temperature protection
Natural convection cooling without a fan
LED indicator for power-on status
100% full-load burn-in test
UL/CUL/TUV/CB/CE safety certifications
Complies with RoHS and UL508 standards for industrial control equipment
The DR-120-24 switching power supply is a reliable and efficient power solution for a wide range of applications. Its compact size and DIN rail mountability make it easy to install and use in various industrial and commercial settings.
