DMC-9940 Other Brands

Description

• DMC-9940 is a stepper motion control card from Galil Motion Control, a leading manufacturer in the field of motion control technology. This card offers advanced features and high performance for precise control of stepper motors in various applications.
• Product Name: DMC-9940 Stepper Motion Control Card
• Product Description:
  The DMC-9940 is a high-performance stepper motion control card designed to provide precise and reliable control of stepper motors. It offers a wide range of features and capabilities, making it suitable for use in various industrial, medical, and scientific applications that require precise positioning and motion control.
• Product Parameters:
• Control Axes: Supports up to 4 axes of stepper motor control.
  Encoder Feedback Frequency: 12 MHz for high-resolution position feedback.
  Step Command Frequency: 3 MHz for fast and responsive motion control.
  Processor: 32-bit dedicated processor for efficient motion processing.
  I/O Points: 8 freely configurable optical coupling input points (5-28 VDC) and 8 programmable output points.
  Expansion Options: Supports additional 64 I/O points for expanded functionality.
  ADC Inputs: Eight 12-bit analog-to-digital converter (ADC) inputs for monitoring analog signals.
  Connectors: 100-pin high-density connector for reduced electromagnetic interference.
• Product Specification:
• Performance:
  Execution Capacity: Full trajectory calculation in continuous path mode, up to 500 moves per second.
  Positioning Accuracy: ±1 pulse.
  Speed Accuracy: Below 0.003% (ten thousandths of a percent).
  Synchronous Control: Simultaneous synchronization of axes within the same card and between multiple cards.
  Position Capture Accuracy: 25 microseconds with optical coupling; 0.1 microseconds without optical coupling.
  Parameters Range:
  Displacement Range: ±2,147,48… (specific range depends on configuration and application)
• Please note that the above information is based on the general specifications and capabilities of the DMC-9940 stepper motion control card from Galil Motion Control. It is recommended to refer to the official product documentation or contact the manufacturer directly for accurate and detailed product specifications, as well as any specific application requirements or limitations.
• DMC-9940
