Description

The BENTLY 3500/22M 138607-01 is a transient data interface(TDI)module provided by Bently Nevada(also known as GE Industrial Solutions).The following is a detailed introduction to this product:

I.Product Overview

The BENTLY 3500/22M 138607-01 transient data interface(TDI)module is the interface between the 3500 monitoring system and compatible software(such as System 1 Condition Monitoring and Diagnostic Software and 3500 System Configuration Software).It combines the functions of the 3500/20 rack interface module(RIM)and the data acquisition capabilities of communication processors(such as TDXnet)to provide key data for monitoring and diagnosis of various rotating equipment.

II.Main functions

Data acquisition:

TDI is able to continuously collect steady-state and transient waveform data,which is very useful for analyzing the operating status of mechanical equipment and diagnosing potential problems.

High-speed data transmission:

Through Ethernet connection,TDI is able to quickly transmit the collected data to the host computer software to ensure the real-time and accuracy of the data.

BENTLY 3500/22M 138607-01

Compatibility and expandability:

BENTLY 3500/22M 138607-01 transient data interface is compatible with 3500 monitoring system and Bently System 1TM machinery management software,and can be easily integrated into existing industrial automation systems.

Integrated functions:

TDI not only has the functions of 3500/20 rack interface module(RIM),but also integrates the data collection function of communication processor,making data acquisition and processing more efficient.

III.Technical specifications

Power consumption:10.5 watts

Front panel interface:USB-B

Network interface:10Base-T or 100Base-TX Ethernet(adaptive),and 100Base-FX fiber optic Ethernet

Rack reset button:available

Data capture capability:

Static data capture is standard with TDI.

With optional channel enable disk,TDI can also capture dynamic and high-resolution transient data.

4.Application Field

BENTLY 3500/22M 138607-01 transient data interface module is widely used in industrial automation and mechanical equipment monitoring,including but not limited to rotating equipment monitoring and diagnosis in industries such as petroleum,chemical,and power.

5.Installation and Configuration

Installation location:TDI is installed in the slot adjacent to the 3500 cabinet power supply,usually occupying slot 1 of the rack(next to the power supply).

Connection:TDI is connected to M series monitors(such as 3500/40M,3500/42M,etc.)to continuously collect steady-state and transient dynamic(waveform)data.

Configuration:Configure and set up through compatible software to meet specific monitoring and diagnostic needs.

BENTLY 3500/22M 138607-01
