ANC-100E AN-X2-AB-DHRIO Automation Converter Ethernet/IP to DH+Converter

　　Product Description

　　The ANC-100E AN-X2-AB-DHRIO Automation converter connects the Ethernet/IP network to the DH+network,enabling data transmission and signal conversion.

　　Features

　　Allow communication between Ethernet/IP and DH+networks

　　Easy to install and configure

　　Reliable and efficient data transmission

　　The ANC-100E AN-X2-AB-DHRIO automation converter is designed to facilitate communication between Ethernet/IP and DH+networks.It achieves seamless integration and data exchange between devices using these protocols.

　　ANC-100e is a compact,high-performance,industrial grade Ethernet DH+to USB converter and data highway to Ethernet converter,USB to DH+.Its features include:easy configuration through web interface and DH+automatic polarity detection and DH+automatic baud rate detection.

　　The design of the AN-X2-AB-DHRIO gateway is to assist customers in initiating phased migration methods to replace or upgrade traditional remote I/O PLCs,HMI,drivers,or Flex I/O adapters.These solutions can be implemented by selecting the corresponding operating mode during the initial configuration period.AN-X2-AB-DHRIO has a built-in web server that can display diagnostic data,configure,upload configuration files,and set operating modes.

　　The EtherNet/IP to Remote I/O or Data Highway Plus DH+(AN-X2-AB-DHRIO)gateway is designed to assist customers in initiating phased migration methods to replace or upgrade traditional remote I/O,HMI,or drives.The AN-X2-AB-DHRIO gateway has multiple operating modes selected during initial configuration,as described below.

　　This mode serves as a bridge between EtherNet/IP and DH+Data Highway Plus networks.

　　*Programming terminals and/or processors on EtherNet/IP networks can access legacy processors on the Data Highway Plus DH+network

　　*Download to PLC5 or SLC through RSLinx

　　*Configure through a web browser and support all Data Highway Plus DH+baud rates(57.6,115.2,and 230.4 K baud)

　　*Communication must be initiated from the EtherNet/IP side,DH+messages cannot be sent to EtherNet/IP devices

　　*Support DH+to EtherNet/IP PanelViews upgrade on PLC5 or SLC networks

　　ANC-100e,RSINX Ethernet/IP to Allen Bradley data highway plus(DH+)gateway converter series,replacing Prorand An2-ab dhrio.ANC-100E is an economical and high-performance,”pocket”converter interface for factory automation equipment Ethernet/IP and the Allen Bradley data highway with DH+between PLC-5S and SLC-504S.

　　Application field

　　The ANC-100E AN-X2-AB-DHRIO Automation converter is widely used for converting Ethernet/IP networks to DH+networks.Therefore,it may be applied in any field that requires the conversion of these two network protocols,including but not limited to industrial automation,process control,data monitoring,and other fields.
