ABB IMHSS03

Description

ABB IMHSS03 is a hydraulic servo module that is a valve position control module 1.

ABB

IMHSS03 is used to monitor and adjust the operation of the hydraulic transmission system for precise control and adjustment2. It provides an interface where the sound controller can drive a servo valve or I/H converter, providing manual control or automatic control of hydraulic actuators. Typical uses are to locate turbine throttle and control valves, gas turbine fuel valves, inlet guide blades, and nozzle angles. By adjusting the current of the servo valve, the IMHSS03 module can initiate the change of the actuator position 1.

ABB IMHSS03 specifications are as follows:

Processor: Cirrus LOGIC EP9315, main frequency 200MHz.

Kernel: ARM920T.

Memory: On-board 64MB SDRAM/32MB NorFlash.

Operating system: Support LINUX2.6.17 operating system; Supports Windows 4.2, 5.0, and 6.0 operating systems.

Motherboard structure: Embedded 3.5-inch industrial computer motherboard structure.

ABB IMHSS03 parameters are 1:

4 analog inputs, 2 LVDT secondary inputs (each with 2 secondary).

3 optically isolated (250VDC) contact inputs (lift, drop, and trip deviation).

1 independent, optically isolated (250VDC), open collector output (hard manual).

2 analog outputs: LVDT Primary 1 and 2.

ABB IMHSS03 uses Cirrus LOGIC EP9315 microprocessor design, main frequency of 200MHz, with 2D graphics, floating point arithmetic coprocessor. Specifications: Embedded 3.5-inch industrial computer motherboard structure. Onboard Cirrus LOGIC EP9315, main frequency 200MHz. The kernel is ARM920T. Onboard 64MB SDRAM/32MB NorFlash. LINUX2.6.17 operating system supported; Supports Windows 4.2, 5.0, and 6.0 operating systems. Three USB HOST ports on board; On-board five-channel 232 serial port; Onboard conventional two RS485 serial port; On-board PS2 mouse and keyboard interface; Onboard TFT-LCD, support 3.5-inch to 17-inch TFT-LCD LCD screen 2.
