Description

ABB-5SHY4045L0006-3BHB030310R0001-3BHE039203R0101-GVC736CE101-5SXE12-0184 is a high-voltage power electronic module produced by ABB Switzerland, a leading manufacturer of power and automation technologies. This module is specifically designed for HVDC (High-Voltage Direct Current) transmission and conversion applications, providing exceptional efficiency, power density, reliability, and long service life.

Product Details:

The ABB-5SHY4045L0006-3BHB030310R0001-3BHE039203R0101-GVC736CE101-5SXE12-0184 module is composed of multiple components, including an IGBT (Insulated Gate Bipolar Transistor) module, a buffer module, a driver module, a thyristor module, and a heat sink. These components work together to ensure the stable and efficient operation of the module under high-voltage conditions.

Specifications & Parameters:

The module has a rated voltage of 4500 V and a rated current of 4000 A, making it suitable for handling high-power applications. It also exhibits low switching losses and high reliability, ensuring efficient performance and reduced maintenance costs. The module’s dimensions are 220 mm in length, 180 mm in width, and 80 mm in height, with an installation hole distance of 200 mm, facilitating easy integration into existing systems.

Functionalities:

The high switching frequency of this module contributes to its high efficiency and power density, making it ideal for demanding industrial applications. The low losses associated with the module result in reduced heat generation and improved overall system efficiency.

Application Fields:

ABB-5SHY4045L0006-3BHB030310R0001-3BHE039203R0101-GVC736CE101-5SXE12-0184 finds widespread use in various industries, including renewable energy (such as wind turbines and solar power systems), electric vehicles, railway transportation, and industrial motor drives. Its ability to handle high voltages and currents effectively, combined with its excellent performance characteristics, make it a valuable component in modern power electronic systems.

In summary, the ABB-5SHY4045L0006-3BHB030310R0001-3BHE039203R0101-GVC736CE101-5SXE12-0184 high-voltage power electronic module is a robust and efficient solution for HVDC transmission and conversion applications, offering reliable performance and long service life.
