ABB 5SHY3545L0016 3BHB019719R0101 GVC736BE101 5SXE06-0160

Based on the information available, here is a detailed breakdown of the ABB 5SHY3545L0016 3BHB019719R0101 GVC736BE101 5SXE06-0160 product in English:

Product Parameters:

• Brand: ABB
• Model: 5SHY3545L0016 3BHB019719R0101
• Additional Codes: GVC736BE101 5SXE06-0160
• Series: 5SHY Series IGCT (Integrated Gate Commutated Thyristor)

Specifications:

• Maximum Rated Current: 3500 A¹
• Maximum Rated Voltage: 4500 V¹
• Maximum Rated Switching Loss: 14000 W¹
• Maximum Rated Switching Frequency: 1600 Hz¹
• Maximum Rated Junction Temperature: 175°C¹
• Minimum Rated Gate Pulse Current: 10 mA¹
• Minimum Rated Gate Pulse Voltage: 15 V¹
• Chip Count: 1¹
• Cooling Method: Water-cooled¹
• Package Type: TO-247AB¹

Physical Dimensions and Weight:

• Specific physical dimensions and weight might not be directly available, but as it’s an IGCT module, it is typically designed for integration within larger systems and may vary based on the exact package and cooling requirements.

Series:

• The product belongs to the 5SHY series of IGCT (Integrated Gate Commutated Thyristor) modules from ABB.

Features:

• Integrated Design: IGCT combines GTO (Gate Turn-Off Thyristor) chips with anti-parallel diodes and gate drive circuits, offering a compact and efficient solution².
• High Current and Voltage Capability: Capable of handling high currents (up to 3500 A) and voltages (up to 4500 V), making it suitable for medium- to high-power applications¹.
• Fast Switching: With a high switching frequency of up to 1600 Hz, IGCT enables efficient power control and conversion¹.
• Reliability and Low Losses: IGCTs exhibit low conduction losses and high reliability due to their design, reducing the need for additional buffer circuits².
• Cost-effective: IGCTs are cost-effective solutions for power systems, offering a balance between performance and cost².

Applications:

• The ABB 5SHY3545L0016 3BHB019719R0101 GVC736BE101 5SXE06-0160 IGCT module is typically used in power systems, such as grid installations (up to 100MVA) and medium-power industrial drives (up to 5MW)⁵.
• It can be integrated into various power electronics systems, including medium-voltage converters, motor drives, and renewable energy systems, where precise and efficient power control is required.

Note:

• The specific dimensions, weight, and some additional details might not be available directly from the given information. It’s recommended to consult the official ABB product datasheet or contact ABB directly for the most accurate and up-to-date information.
• Always ensure proper handling and installation of electrical components, and consult qualified professionals for system integration and maintenance.
