ABB 100472-012

Description

Product Name: ABB 100472-012 DC Brushless Motor

Product Description:

The ABB 100472-012 DC Brushless Motor is a compact and efficient motor designed for a wide range of applications. It features a brushless design, which provides longer motor life and reduced maintenance requirements. The motor is suitable for use in various industrial automation, robotics, and other similar applications.

Product Parameters:

• Voltage: 24 VDC
• Current: 1.5 A
• Torque: 0.6 Nm
• Number of poles: 4
• Shaft diameter: 6 mm
• Mounting hole distance: 20 mm
• Mounting hole diameter: M3
• Weight: 190 g

Specifications:

1. Construction: The motor is made of high-quality materials and features a robust design for reliable performance. It is suitable for both continuous and intermittent duty cycles.
2. Efficiency: The motor has a high efficiency rating, which helps to reduce energy consumption and operating costs. It also provides faster acceleration and deceleration times.
3. Torque: The rated torque of the motor is 0.6 Nm, which is sufficient for most applications. The motor can produce higher torque at higher speeds, making it suitable for various load conditions.
4. Dimensions: The motor has a compact size, making it easy to integrate into various systems and applications. The shaft diameter, mounting hole distance, and mounting hole diameter have been designed for easy installation and compatibility with standard components.
5. Mounting: The motor can be mounted in various positions, depending on the specific application requirements. It features threaded mounting holes that allow for easy attachment to the system frame or other components.
6. Control and Integration: The motor can be controlled using various electronic speed controllers or integrated into automated systems using appropriate interfaces and communication protocols. It is suitable for use with various sensors and feedback devices to achieve precise control and positioning.
7. Warranty: ABB provides a limited warranty on the 100472-012 DC Brushless Motor, ensuring reliability and performance throughout its service life. It is important to note that the warranty may be voided if the motor is used outside of its specified parameters or if it is not properly maintained and cared for according to the manufacturer’s recommendations.

Please refer to the official ABB product manual for detailed specifications, datasheets, and troubleshooting information if further assistance is required.
