ABB 086318-002

Description

ABB’s 086318-002 is a powerful analog module.The following is a detailed introduction to it:

1.Product Overview

The 086318-002 module is a high-performance analog module produced by the ABB brand,suitable for industrial areas such as power plants and steel plants.It integrates multiple functions such as signal conditioning,sensor power supply,data acquisition and data storage,and can connect different sensors to directly complete the test and recording of dynamic signals.

ABB 086318-002

2.Technical Specifications

Number of channels:The module has 8 parallel channels.One host computer can control 16 parallel collectors at the same time,and the total number of channels can reach 128CH.

A/D resolution:14Bit,which can provide high-precision analog measurement.

Sampling rate:1MHz/CH,supports high-speed data acquisition.

Storage depth:512K samples per channel,meeting the needs of long-term data acquisition and storage.

Trigger mode:supports multiple trigger modes such as manual trigger,internal trigger,external trigger and full channel trigger,which is convenient for users to choose according to different application scenarios.

Filter:Provides pass-through and low-pass filters,and the frequency range of the low-pass filter is adjustable from 1.5K to 100K.

Signal input:Supports multiple signal input methods such as voltage V,charge Q,ICP,etc.,to adapt to the output signals of different sensors.

Communication interface:Adopts RJ45 Ethernet interface,which is convenient for data communication with the host computer or other devices.

Excitation voltage/current:Provides two excitation methods of bridge voltage 2V8V/520mA and constant current 4mA/24V to meet the excitation requirements of different sensors.

Power supply:Adopts AC220V/50Hz power supply to ensure the stable operation of the module.

ABB 086318-002

III.Functional features

Plug-in module design:The strain amplifier module and charge amplifier module adopt plug-in design.Users can replace the front-end conditioning module as needed,which is convenient for maintenance and upgrading.

One machine three uses:This module can not only be used as a data collector,but also as a strain/charge amplifier and high-speed data acquisition system to meet the needs of various application scenarios.

Software support:Equipped with NoisA1.0 noise test software and PFM1.0 pulsation monitoring software,it is convenient for users to collect,analyze and process data.

IV.Application fields

The 086318-002 module is widely used in industrial automation,process control,laboratory testing and measurement and other fields.Especially in application scenarios that require high-precision,high-speed data acquisition and storage,the module performs well.
