Description
Product Description
5136-DN-PC SST DeviceNet Interface Card
Function:Connect the PCI bus computer to the DeviceNet network
Purpose:Used to connect a PC to a DeviceNet network for data collection,control,and other functions
Features:
The entire DeviceNet protocol is executed in hardware
Supports all DeviceNet standard baud rates:125,250,and 500 Kbaud
A complete DeviceNet implementation with state changes and explicit messaging
I/O scanner and device application card level DeviceNet compliance
The SST 5136-DN-PC DeviceNet PC interface card connects the PC bus computer to DeviceNet.The entire DeviceNet protocol is executed in hardware and supports all DeviceNet standard baud rates.
This module adopts a modular design,which is easy to install and maintain.There are 2 LED indicator lights on the front panel of the module to indicate the communication status.There is one connector on the back panel of the module for connecting to the DeviceNet network.
Product parameters:
Supported baud rates:125,250,500 Kbps
Interface type:PCI
Power supply:5V DC
Product specifications:
Size:120 mm x 68.6 mm
Weight:0.2 kg
Application field:
The petroleum and natural gas industry:refineries,chemical plants,pipelines,etc
Chemical industry:chemical plants,pharmaceutical plants,etc
Power industry:power plants,substations,etc
Metallurgical industry:steel mills,aluminum mills,etc
Food and Beverage Industry:Food processing plants,beverage factories,etc
Related products:
DeviceNet Network
PLC
HMI
Additional information:
The DeviceNet interface card is an important bridge connecting PC and DeviceNet network.
This module can achieve functions such as data collection and control of the DeviceNet network on a PC.
This module can be used together with other DeviceNet devices to form a complete control system.
Differences from other DeviceNet interface cards:
Compared with other DeviceNet interface cards,the 5136-DN-PC SST DeviceNet interface card has the following characteristics:
Supports all DeviceNet standard baud rates:5136-DN-PC supports all DeviceNet standard baud rates,which can meet different application requirements.
Supporting both client and server operations:5136-DN-PC can perform both client and server operations simultaneously,making it more powerful.
Has isolation function:5136-DN-PC has isolation function,which can improve the safety of the system.
Easy to install and maintain:The 5136-DN-PC adopts a modular design,making it easy to install and maintain.
