Description
Technical Specifications for 2711-T14C15
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711-T14C15 |
| Power Type | AC |
| Supply Voltage Limit | 85-264 Volts; 43-63 Hertz |
| Power Consumption | 200 VA max |
| Comm Port | ControlNet |
| Total Application Flash Memory | 1008 Kbytes |
| Operating Shock | 15 g |
| Non-Operating Shock | 30 g |
| Operating Temperature | 32-131 F (0-55 C) |
| Dimensions | 13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm) |
| Display Dimensions | 10.0 x 7.5 in (255 x 191 mm) |
| Weight | 43.2 lbs (19.6 kg) |
| Method of Input | Touchscreen |
| Product Lifecycle Status* | Discontinued/Obsolete |
*The Allen Bradley 2711-T14C15 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-T14C15 units instead of migration.
About 2711-T14C15
The Allen-Bradley 2711-T14C15 is a PanelView standard 1400 terminal. It features a color CRT touchscreen display that measures 14 inches. The terminal’s screen is made up of 384 touch cells arranged in 24 columns by 16 rows. Each touch cell is 33 x 37 pixels in size and the screen has an 800 x 600-pixel resolution. Note that the 2711-T14C15 terminal does not have any keypad input. This Series B terminal has two communication ports available: one ControlNet communication port and one RS-232 printer port. It also comes with an IP54/IP65 protection and is housed in a NEMA Type 12/13 or 4x enclosure that can only be used indoors. The built-in indicators allow users to monitor the status of the terminal. A 1008-KB flash memory is also included in the terminal.
It has a maximum power consumption of 200 VA and with supply voltage limits of 85 to 264 Volts AC and 43 to 63 Hertz. The entire terminal weighs 43.2 pounds and has a total measurement of 13.97 x 17.37 x 15.53 inches. Its operating temperature range is from 0 to 55 degrees Celsius and storage temperature range is from -40 to 85 degrees Celsius. The terminal has a heat dissipation of 78 W or 264 BTU/hour, with a non-condensing relative humidity of 5 to 95% at 0 to 55 degrees Celsius. It also has a non-operating shock of 30g, an operating shock of 15g, and an operating vibration of 1g at up to 2000 Hertz.
