2711C-T10C ALLEN BRADLEY

The 2711C-T10C is an Allen-Bradley PanelView Component C1000 Terminal. The Panel View Component C1000 Terminal is the most advanced component terminal in the AB series used for high-end applications that use Ethernet or serial communications. This device has Color Transmissive TFT and active matrix LCD that have the ability to interface with most of the controllers and programming ports. It is optimized for communication with MicroLogix, SLC500 controller and Micro800 controllers.

The 2711C-T10C operator interface comes with 10-inch touchscreen display interface and is accessible from a web browser using an Ethernet connection using emulator address like 169.254.253.9. It has a lithium battery on the back of the unit that provides battery backup for the real-time clock, making it possible to save the operations there. It uses a CCFL indicator for process identification. Apart from a USB port as a memory card, the 2711C-T10C has an enhanced add-on useable as an SD card as well.

The 2711C-T10C is powered by a 24 Volts DC external supply voltage and has a power consumption of 18 Watts.It is certified as 2711C-T10C cULus Listed; CE marked; C-Tick. The temperature of the terminal must be greater than 32 degrees Fahrenheit during the installation of the panel. It also has an option to alert the operators using alarm messages using different variables. With a screen resolution of 640 x 480, it is the most advanced interfacing component. Weighing approximately 3.41 pounds with a display size of 10.4 211 x 158 millimeters (8.31 x 6.22 inches), the PanelView Component C1000 terminal has a backlight time of more than 50,000 hours. This operator terminal can be mounted vertically against the panel or tilted at an angle of 45 degrees.
