Description
Technical Specifications for 2711C-T10C
| Input Type | Touch |
| Compatible Web Browsers: | Internet Explorer 7 and 8, Firefox 3.0 |
| Input Voltage range: | 18…30V DC (24V DC nom) |
| Communication ports: | RS-232 (DH-485), RS-232 (DF1), RS-485 Multi-vendor communication available for Modbus and Siemens MPI devices; USB Port |
| Touchscreen: | Analog touch Actuation rating: 1 million presses |
| Backlight: | 50,000 hours life, min; not replaceable |
| Display Type: | Color transmissive TFT active matrix LCD |
| Display Area: | 211 x 158 mm (8.31 x 6.22 in.) |
| Product Type: | PanelView 1000 Component |
| Product Family: | PanelView Component |
| Brand | Allen-Bradley |
| Manufacturer: | Rockwell Automation |
| Resolution | 640 x 480 |
| Product Line | Component Terminal |
| Series | C1000 |
| Part Number/Catalog No. | 2711C-T10C |
| Display Size | 10 in. |
| Display Color | Color |
| Power | 24 Volt DC |
| Power Consumption | 5 Watts |
| UPC | 887172659768 |
| Product Lifecycle Status* | Discontinued/Obsolete |
*The Allen Bradley 2711C-T10C has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711C-T10C units instead of migration.
About 2711C-T10C
The 2711C-T10C operator interface comes with 10-inch touchscreen display interface and is accessible from a web browser using an Ethernet connection using emulator address like 169.254.253.9. It has a lithium battery on the back of the unit that provides battery backup for the real-time clock, making it possible to save the operations there. It uses a CCFL indicator for process identification. Apart from a USB port as a memory card, the 2711C-T10C has an enhanced add-on useable as an SD card as well.
The 2711C-T10C is powered by a 24 Volts DC external supply voltage and has a power consumption of 18 Watts.It is certified as 2711C-T10C cULus Listed; CE marked; C-Tick. The temperature of the terminal must be greater than 32 degrees Fahrenheit during the installation of the panel. It also has an option to alert the operators using alarm messages using different variables. With a screen resolution of 640 x 480, it is the most advanced interfacing component. Weighing approximately 3.41 pounds with a display size of 10.4 211 x 158 millimeters (8.31 x 6.22 inches), the PanelView Component C1000 terminal has a backlight time of more than 50,000 hours. This operator terminal can be mounted vertically against the panel or tilted at an angle of 45 degrees.
