Description
Technical Specifications for 2711C-K3M
| Input Voltage range: | 18…30V DC (24V DC nom) |
| Keypad function keys: | 10 function keys (F1…F10) |
| Backlight: | 50,000 hours life, min; not replaceable |
| Display Area: | 67 x 33 mm (2.64 x 1.30 in.) |
| Display Type: | Monochrome transflective FSTN passive matrix |
| Product Type: | PanelView 300 Component |
| Product Family: | PanelView Component |
| Manufacturer: | Rockwell Automation |
| Communication ports: | RS-232 (DH-485), RS-232 (DF1), RS-485 Multi-vendor communication available for Modbus and Siemens MPI devices; USB Port |
| Brand | Allen-Bradley |
| Compatible Web Browsers: | Internet Explorer 7 and 8, Firefox 3.0 |
| Input Type | Keypad |
| Resolution | 128 x 64 |
| Product Line | Component Terminal |
| Series | C300 |
| Part Number/Catalog No. | 2711C-K3M |
| Display Size | 3 inches |
| Display Color | Monochrome |
| Power | 24 Volts DC |
| Power Consumption | 5 Watts |
| Weight | 0.43 pounds |
| Product Lifecycle Status* | Discontinued/Obsolete |
*The Allen Bradley 2711C-K3M has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711C-K3M units instead of migration.
About 2711C-K3M
The 2711C-K3M operator interface comes with a 3-inch display with embedded touch membrane. It has a built-in web browser allowing remote access through Ethernet connection using an emulator address. This operator terminal is installed using mounting and quick-lever clamps which makes the maintenance and installation process easy and convenient. It also has a backup available for at least 5 years and no real-time clock, the terminal is valuable when viewing the results on the terminal during large applications.
The 2711C-K3M uses 24 Volts DC input voltage. For device safety, give the terminal connections regular maintenance. Version 2. The operator input has 10 functional keys which are keys F1 to F10, a numeric keypad with keys from 0 to 9, and up, down, left, right, decimal, +/-, and Enter keys with a USB port as a programming port. The users can view the system information and apply login passwords for secure operations. With a screen resolution of 128 by 64 pixels, it comes with a built-in analog touchscreen. Weighing less than 0.43 pounds with a display size of 67 by 33 millimeters (2.64 by 1.30 inches), the PanelView Component C300 Terminal has a backlight life of more than 50,000 hours. The files can be transferred through the PanelView Component terminal storage and a USB flash drive or a computer.
