Description
Technical Specifications for 2711-K5A8
| Enclosure: | NEMA Type 12/13, 4X (Indoor use only), IP54, IP65 |
| Application memory: | 170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps) |
| Keypad Assembly: | 10 function keys (F1…F10) |
| Resolution: | 256 x 128 |
| Display Area: | 120 x 60 mm (4.75 x 2.38 in.) |
| Display Type: | Monochrome transflective LCD with LED backlight |
| Operator Input: | Keypad |
| Product Type: | PanelView 550 Standard Operator Terminals |
| Product Family: | PanelView Standard Operator Terminals |
| Manufacturer: | Rockwell Automation |
| Communication ports: | DH+; RS232 (printer) |
| Input Voltage range: | 85…264V AC |
| Input Frequency: | 47…63 Hz |
| Brand | Allen-Bradley |
| Status Indicators: | COMM: Green Fault: Red |
| Backlight | 100,000 hr LED backlight life |
| Part Number/Catalog No. | 2711-K5A8 |
| Product Line | PanelView 550 |
| Display Size | 5.5 inches |
| Display Color | Monochrome LCD blue mode |
| Input Type | Keypad (F1-F10) |
| Communication | DH+ Communication and RS-232 Printer Port |
| Input Power | 120 Volts AC |
| Memory | 170 KB application runtime |
| Communication Cable | 2711-NC13 |
| Shipping Weight | 6 pounds |
| Shipping Dimensions | 14 x 11 x 8 inches |
| Series | A, B, C, D, E, F, G, H |
| UPC | 10662072073725 |
| Product Lifecycle Status* | Discontinued/Obsolete |
*The Allen Bradley 2711-K5A8 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-K5A8 units instead of migration.
About 2711-K5A8
The 2711-K5A8 keypad offers functional control through 10 function keys, Numeric keys and navigation keys. For the users who wish to use a different bezel than the standard model, a stainless-steel rim upgrade option is also available.
The 2711-K5A8 keypad has a display size of 5.5 inches and 240 KB non-volatile memory and 170 KB of Random Access Memory (RAM). The keypad can be removed from Allen-Bradley PanelView Standard 550 terminals according to troubleshooting requirements which may require the replacement or repair of the 2711-K5A8 keypad module.
Process or machine operators interacts with the process using the embedded keypad that is composed of Ten (10) function keys, numeric and navigation keys. The function keys may be assigned with variable assignments such as global and local function. The numeric keys allow entry of analog variable and constants while the navigation buttons are used for screen and object selection.
