Description
Technical Specifications for 2711-K5A5
| Input Frequency: | 47…63 Hz |
| Resolution: | 256 x 128 |
| Display Area: | 120 x 60 mm (4.75 x 2.38 in.) |
| Display Type: | Monochrome transflective LCD with LED backlight |
| Operator Input: | Keypad |
| Product Type: | PanelView 550 Standard Operator Terminals |
| Product Family: | PanelView Standard Operator Terminals |
| Manufacturer: | Rockwell Automation |
| Keypad Assembly: | 10 function keys (F1…F10) |
| Application memory: | 170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps) |
| Communication ports: | RS232 (DH485) |
| Input Voltage range: | 85…264V AC |
| Enclosure: | NEMA Type 12/13, 4X (Indoor use only), IP54, IP65 |
| Status Indicators: | COMM: Green Fault: Red |
| Brand | Allen-Bradley |
| Backlight | 100,000 hr LED backlight life |
| Part Number/Catalog No. | 2711-K5A5 |
| Product Line | Panelview 550 |
| Display Size | 5.5 inches |
| Display Color | Monochrome LCD blue mode |
| Input Type | Keypad(F1-F10) |
| Communication | RS-232 (DH-485) Communication Port |
| Input Power | 120 Volts AC |
| Memory | 170 KB application runtime |
| Communication Cable | 2711-NC13 |
| Shipping Weight | 6 pounds |
| Shipping Dimensions | 14x11x8 inches |
About 2711-K5A5
The 2711-K5A5 Human Machine Interface (HMI) is capable of connecting single or multiple processes however, ideally used for small applications as it has a 5.5-inch screen with display area of 120 x 60 mm (4.75 x 2.38 in.) and resolution of 256 x 128. Control is implemented using the keypad assembly which features Ten (10) function keys that can be assigned with local and global variables. It also has numeric and navigation keys that are used to enter variables and select objects, icons and move from one screen to another.
This HMI device communicates with partner automation devices through the embedded RS232 serial port that is compatible with DH485 communication protocol. For networked connections, this embedded communication port may be partnered with Allen-Bradley network interface cards.
