Description
Technical Specifications for 2711-K5A1
| Backlight | 100,000 hr LED backlight life |
| Status Indicators: | COMM: Green Fault: Red |
| Enclosure: | NEMA Type 12/13, 4X (Indoor use only), IP54, IP65 |
| Input Frequency: | 47…63 Hz |
| Input Voltage range: | 85…264V AC |
| Communication ports: | Remote I/O (RIO); RS232 (printer) |
| Application memory: | 170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps) |
| Keypad Assembly: | 10 function keys (F1…F10) |
| Resolution: | 256 x 128 |
| Display Area: | 120 x 60 mm (4.75 x 2.38 in.) |
| Display Type: | Monochrome transflective LCD with LED backlight |
| Operator Input: | Keypad |
| Product Type: | PanelView 550 Standard Operator Terminals |
| Product Family: | PanelView Standard Operator Terminals |
| Manufacturer: | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711-K5A1 |
| Product Line | Panelview 550 |
| Display Size | 5.5 in. |
| Display Color | Monochrome LCD blue mode |
| Input Type | Keypad(F1-F10) |
| Communication | Remote I/O Communication and RS-232 Printer Port |
| Input Power | 120 VAC |
| Memory | 170 KB application runtime |
| Communication Cable | 2711-NC13 |
| Shipping Weight | 6 lbs |
| Shipping Dimensions | 14x11x8 inches |
| Series | A,B,C,D,E,F,G,H |
| UPC | 883809653284 |
| UNSPSC | 43211902 |
| Product Lifecycle Status* | Discontinued/Obsolete |
*The Allen Bradley 2711-K5A1 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-K5A1 units instead of migration.
About 2711-K5A1
The 2711-K5A1 is a Human Machine Interface (HMI) device that is part of Allen-Bradley’s bulletin 2711 PanelView Standard Operator terminals. This product category is an obsolete product line with an industrially approved assembly, able to operate and withstand the demanding requirements of the automation industry.
The 2711-K511 comes with a rugged design which primarily featured a 5.5-inch display screen, with display area of 120 x 60 mm (4.75 x 2.38 in.) where monochrome process or machine mimic display may be designed to effectively reflect the status of operation of any connected application. This HMI is capable of displaying industrial graphical representation, texts and symbols related to the process. This monochrome screen provides the process visualization.
Control and interaction to the machine or process is initiated through the embedded keypad which is composed of Then (10) function keys, numerical key set and navigational buttons. These keypads enable the operator to enter commands, modify parameters, interact to system alarms and messages and navigate to different HMI screens.
Communication with controllers is implemented through the built-in Remote I/O (RIO) communication terminal that supports daisy-chain topology, using Belden 9463 cable. It also has a single RS232 Printer port that is specifically used for communicating with printers for documentation of alarm logs.
2711-K5A1 ALLEN BRADLEY
2711-K5A1 ALLEN BRADLEY
