Description
Technical Specifications for 2711-K10C1
| ATA memory card: | Supported |
| Product Type: | PanelView 1000 |
| Product Family: | PanelView Standard |
| Manufacturer: | Rockwell Automation |
| Display Type: | Color active matrix TFT |
| Display Area: | 211 x 158 mm (8.3 x 6.2 in.) |
| Resolution: | 640 x 480 |
| Backlight: | 50,000 hr 1/2 life at 25 °C (77 °F) |
| Keypad function keys: | 16 function keys (F1…F16) |
| Application memory: | 310KB application runtime; 1008 KB nonvolatile memory (application objects plus text and bitmaps) |
| Communication ports: | Data Highway Plus (DH+); RS232 (Printer) |
| Input Voltage range: | 85…264V AC, 47…63 Hz |
| Accessories: | function key legend inserts; Anti-glare overlays; backlight replacements; Real-time clock replacements; Mounting hardware; Power supply and terminal block; interface modules; |
| Weight: | 3.7 kg (8.2 lb) |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711-K10C1 |
| Product Line | Panelview 1000 |
| Display Size | 10.1 in. |
| Display Color | Multi-Color |
| Input Type | Keypad |
| Communication | Printer (RS-232) Port and Remote I/O |
| Input Power | 85-264 Volts Alternating Current |
| Memory | 256 Kilobytes |
| Enclosure Type | NEMA Type 12/13 or 4X |
| Product Lifecycle Status* | Discontinued/Obsolete |
*The Allen Bradley 2711-K10C1 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-K10C1 units instead of migration.
About 2711-K10C1
The 2711-K10C1’s colored display screen allows creation of detailed process mimic with color coded designs and animations. This functionality provides more information such as easily identify the type of material flowing within a pipe, identification of process area, identifying or process alarms and events and other relevant status. The display screen has an effective display area of 211 x 158 mm (8.3 x 6.2 in.) and resolution of 640 x 480 pixels.
for interfacing with the process or machine, control may be initiated via the Sixteen (16) function keys, from F1 to F16 that are fully programmable, whether local or global assignment. The function keys are Stainless-steel domed membrane with an actuation lifespan of 1 million presses.
For data exchange, the 2711-K10C1 has embedded Remote I/O (RIO) interface port supporting daisy-chain architecture. It also has an onboard RS232 communication port for sending print queues to an alarm printer for alarm logging purposes.
