Description
Technical Specifications for 2711-B6C2
| Brand | Allen-Bradley |
| Accessories: | function key legend inserts; Anti-glare overlays; backlight replacements; Real-time clock replacements; Mounting hardware; Power supply and terminal block; interface modules; |
| Input Voltage range: | 85…264V AC, 47…63 Hz |
| Communication ports: | DeviceNet; |
| Application memory: | 170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps) |
| Keypad function keys: | 10 function keys (F1…F10) |
| Touchscreen: | Touch cells: 128 Actuation: 1 million presses |
| Resolution: | 320 x 234 |
| Display Area: | 115 x 86 mm (4.54 x 3.4 in.). |
| Display Type: | Color active matrix TFT |
| Product Type: | Operator Terminals |
| Product Family: | PanelView Standard Terminals |
| Manufacturer: | Rockwell Automation |
| Input Type | Keypad / Touch |
| Backlight | 50,000 hr 1/2 life at 25 °C (77 °F) |
| Part Number/Catalog No. | 2711-B6C2 |
| Product Line | Panelview 600 |
| Display Size | 5 inches |
| Display Color | Color |
| Communication | DH-485 |
| Input Power | 85 to 264 Volts AC |
| Memory | 256 MB RAM |
| Communication Cable | 1747-UIC |
| Shipping Weight | 6 pounds |
| Shipping Dimensions | 14 x 11 x 8 inches |
| Series | A, B, C, D, E, F, G, H, I, J, K, and L |
| Flash Storage | 512 MB |
| UPC | 10662072660185 |
| Product Lifecycle Status* | Discontinued/Obsolete |
*The Allen Bradley 2711-B6C2 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711-B6C2 units instead of migration.
About 2711-B6C2
The 2711-B6C2 terminal is an Allen-Bradley PanelView 600 operator terminal. The DH-485 terminals are capable of point-to-point communication with a single SLC 500 or MicroLogix controller. The 2711-B6C2 is compatible for use with the 1747-UIC communication adapter for connecting the 2711-B6C2 to a DH485 network. It also includes a keypad and a touchscreen on the HMI for input interface.
The 2711-B6C2 is powered with an external voltage supply range of 85 – 264 VAC. It is installed with an internal memory amounting to 240 KB. The 2711-B6C2 has an internal processor with speed up to 1 GHz. This module’s HMI display is measures 5 inches diagonally, with a field replaceable backlight, and comes with a full-color graphics. The screen transition rate for the 2711-B6C2 is up to 70% faster than it is for other terminals and it comes with an increased memory capacity ranging from 64 MB of RAM to 256 MB of RAM. The flash storage space is increased from 64 MB to 512 MB and it includes 80 MB of nonvolatile storage memory for applications.
2711-B6C2 ALLEN BRADLEY
2711-B6C2 ALLEN BRADLEY
2711-B6C2 ALLEN BRADLEY
