2094-BC01 ALLEN BRADLEY

The Allen-Bradley 2094-BC01-MP5-M is a Kinetix 6200 modular multi-axis servo drive. It is an Integrated Axis (power) Module (IAM) with a Safe Speed Monitor and 460V AC three-phase input power. It contains a 6kW converter and a 5 A inverter section. It requires one control module. The 2094-BC01-MP5-M has dimensions of 4.9 x 11.9 x 13.2 in. and weighs 12.5 lbs.

The 2094-BC01-MP5-M drive is designed to provide Integrated Motion capability for motor or drive applications. The drive can easily transition from Safe Torque Off to Safe Speed Monitor, and from SERCOS interface to EtherNet/IP networks. It is compatible with the Kinetix 6000 servo drive for easy migration whenever needed. The 2094-BC01-MP5-M’s embedded safety feature removes the need for additional panel space and wiring from an external safety monitor. The Safe Speed Monitor functionality allows maintenance work without the need for stopping the machine.

The 2094-BC01-MP5-M drive’s modular design and embedded safety features provide easy maintenance and greater flexibility. It also simplifies wiring, reduces spare parts inventory, and it can be modified with advancing technology. It reduces downtime and energy and production waste and improves operating efficiency with the Safe Speed feature. Its embedded advanced safety features also help protect personnel. The 2094-BC01-MP5-M does not start and stop frequently, thus reducing wear on the motor and maintenance cost. Other safety features include Safe Maximum Speed, Safe Maximum Acceleration Monitoring, Safe Direction Monitoring, Zero Speed Monitoring, Enabling Switch Control, and Door Monitoring and Control. The 2094-BC01-MP5-M has enhanced diagnostic features which tell the nature of the fault by displaying error messages.
