Description
Technical Specifications for 1794-IT8
| Brand | Allen-Bradley |
| Keyswitch Position | 3 |
| Module Location: | 1794-TB2, -TB3 and -TB3T Terminal Base Units |
| CJC unit: | A-B Part Number 969424–0 |
| Indicator: | 1 red/green power status indicator |
| Data Format: | 16-bit 2’s complement or offset binary (unipolar) |
| millivolt signal: | +/- 76. 5mV |
| Sensors supported: | J, K, E, R, N, S, B, C, T and L |
| No. of Inputs: | 8 |
| Part Number: | 1794- IT8 |
| Product Family: | Flex I/O Modules |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Part Number/Catalog No. | 1794-IT8 |
| Product Type | Thermocouple / milivolt Input Module |
| Resolution | 16 bits (2.384 microvolts typical) |
| Power Dissipation | 3W maximum @ 31.2V |
| Inputs | 8 Channels |
| Nominal Input Ranges | -76.5 to 76.5 mV |
| Isolation Voltage | 850 Volts DC |
| Normal Mode Noise Rejection | -60db at 60 Hertz |
| Channel Bandwidth | 0 to 2.62 Hertz |
| Normal Mode System Throughput | 325 milliseconds |
| Flexbus Current | 20 mA |
| Thermal Dissipation | 10.2 BTU/hour at 31.2 Volts DC maximum |
| UPC | 10612598137838 |
About 1794-IT8
The 1794-IT8 is Flex I/O analog input module. Specifically, this is a Thermocouple and millivolt input module. It comes with Eight (8) analog input channels, compatible for direct interfacing with Thermocouple sensors such as J, K, E, R, N, S, B, C, T and L and millivolt range of +/-76.5m.
The 1794-IT8 is compatible with any available Flex I/O communication adapter.
This module is a compatible on being operated in Temperature application ranges such as 300 to 1800oC (572 to 3272oF) using Type B Thermocouple; 0 to 2315oC (32 to 4199oF) Type C;–230 to 1000oC (–382 to 1832oF) Type E; –195 to 1200oC (–319 to 2192oF) Type J; –230 to 1372oC (–382 to 2502oF) type K; –270 to 1300oC (–450 to 2372oF) Type N; –50 to 1768oC (–58 to 3214oF) Type R; –50 to 1768oC (–58 to 3214oF) Type S; –195 to 400oC (–319 to 752oF) type T; –175 to 800oC (–283 to 1472oF) type L. Milivolt input signals are practically used with transducers and other instruments that produce non-standard signals. Data exchange with the 1794-IT8 Thermocouple input module is configured using the block transfer operation.
1794-IT8.. ALLEN BRADLEY
