TRICON 4329 Network Communication Module Product Introduction

TRICON 4329 is a key communication module in Invensys Triconex security control system.It is specially designed for industrial automation environments and supports high-reliability network communication and protocol interaction.The following is a comprehensive analysis of its core functions,technical parameters and application fields:

1.Product Overview

Model:TRICON 4329

Type:Network Communication Module(NCM,Network Communication Module)

Brand/Manufacturer:Invensys Triconex

Core functions:

Communication between Tricon controllers and external systems(such as other Tricon controllers,DCS,HMI,databases,etc.)through Ethernet(802.3 standard).

It supports a variety of protocols,including TSAA,MODBUS,OPC,TCP/IP,etc.,compatible with Triconex proprietary protocols and user-defined applications.

2.Technical parameter

Parameter Description

Communication interface with 2 Ethernet ports(BNC connectors)that support dual network configuration:

NET 1:Dedicated to Tricon secure networks(peer protocol and time synchronization).

NET 2:Support external system communication(such as MODBUS,OPC,DDE,etc.).|

|Agreement Support|TSAA,MODBUS,TCP/IP,OPC Server,DDE Server,etc.|

|Input voltage|24 V DC(compatible with 20-30 V DC range)|

|Power consumption|5 W|

|Operating temperature|-40°C to 70°C(industrial-grade wide temperature design)|

|Physical specifications|6U VME module,dimensions about 22 cm×16.9 cm×4.4 cm|

|Security certification|Compliant with IEC 61508 SIL3 standard,suitable for security critical scenarios.|

3.Core functional features

(1)Redundancy and reliability

Dual network redundancy:communication redundancy through two independent Ethernet ports,automatic switching in case of single-channel failure to ensure the continuous operation of the system.

Hardware isolation:The input/output signal adopts optical coupling isolation technology to effectively suppress electromagnetic interference.

(2)Protocol compatibility

Support Triconex proprietary agreements(such as TriStation 1131,SOE event record)and third-party agreements(such as MODBUS,OPC)to facilitate integration with different vendor devices.

Users can develop customized communication applications through the TSAA protocol to meet specific needs.

(3)Industrial design

Wide temperature operation:adapt to harsh industrial environments(such as petroleum,chemical industry,electricity,etc.).

Long-distance transmission:Support optical fiber expansion(single-mode fiber up to 12 km),suitable for distributed control system deployment.

4.Application scenarios

Key areas of security:

Process control:emergency parking system(ESD)and process monitoring of chemical and petrochemical plants.

Power system:automatic control and safety protection of power plants and power grids.

Transportation:linkage of signal control and equipment of railways and airports.

Industry 4.0 and the Internet of Things:Remote monitoring and data analysis are integrated with the cloud platform through Ethernet.
