ABB 5SHX1960L0004 is a high-voltage IGBT(insulated gate bipolar transistor)module produced by ABB,belonging to the 5SHX series.The following is detailed information about the product:

1.Product Overview

Model:5SHX1960L0004

Type:High-voltage IGBT module

Series:5SHX series

Application areas:

Industrial inverter:used for motor drive,variable frequency speed regulation,etc.

Power electronic equipment:such as uninterruptible power supply(UPS),static VAR compensator(SVC),etc.

Renewable energy:wind power generation,solar inverter,etc.

2.Technical parameters

Rated voltage:

Collector-emitter voltage(Vce):3300V

Gate-emitter voltage(Vge):±20V

Rated current:

Collector current(Ic):1960A(may vary due to packaging and heat dissipation conditions)

Switching frequency:

Usually supports higher switching frequencies,suitable for fast switching applications.

Thermal characteristics:

Operating junction temperature range:-40°C to+150°C(depending on the package and heat dissipation design)

Thermal resistance:Low thermal resistance design ensures efficient heat dissipation.

Package form:

Modular design is adopted for easy installation and maintenance.

3.Product features

High reliability:

Adopting advanced IGBT chip technology,it has low conduction loss and switching loss.

Optimized chip design and packaging process improve the reliability and life of the module.

High efficiency:

Low conduction voltage drop and switching loss reduce system energy consumption.

High switching speed improves system response speed.

Easy to integrate:

Modular design is easy to integrate with other power electronic devices.

Provide a variety of packaging forms to meet different application requirements.

Environmentally friendly:

Comply with environmental protection standards such as RoHS to reduce the impact on the environment.

4.Application scenarios

Industrial automation:

Used for motor drive,variable frequency speed regulation,servo system,etc.

Power system:

Used for high voltage direct current transmission(HVDC),flexible alternating current transmission system(FACTS),etc.

Renewable energy:

Used in wind power generation,solar inverters,energy storage systems,etc.

Transportation:

Used in electric vehicles,rail transit,etc.
