ABB REF542PLUS is a feeder protection and measurement and control unit,which is usually used for the protection and monitoring of medium and low voltage power systems.The following is a detailed introduction to ABB REF542PLUS:

1.Product Overview

ABB REF542PLUS integrates protection,control,measurement and status monitoring functions,and is suitable for distribution network automation.In addition to feeder protection,the device can also be used for transformer and motor protection and control,or for switchgear control alone.The REF542PLUS device has a wide protection setting range and is easy to configure each function block to adapt to various application fields.

2.Main features

Modular design:

REF542PLUS adopts modular design,which is convenient for users to configure and expand according to actual needs.

Real-time multi-function protection and switchgear control:

Provide real-time multi-function protection and switchgear control,including measurement and monitoring of electrical parameters such as current and voltage,as well as circuit breaker opening and closing operations.

Status monitoring and self-diagnosis:

Provides a variety of features to monitor primary equipment and implement self-diagnosis,such as the maximum and average currents within the monitoring cycle,the cumulative value of the breaking current,the operating time,the number of circuit breaker operations,etc.

Powerful communication function:

Equipped with a communication interface,it can communicate with the superior management system(such as the energy management system,the building automation system)to achieve remote monitoring and data acquisition.

Friendly human-machine interface:

Equipped with a large-screen LCD human-machine interface(HMI),which supports multiple language displays,making it convenient for users to operate and monitor.

Easy to install and maintain:

Designed as a compact and easy-to-install structure,it is convenient for users to install and maintain.

III.Application fields

ABB REF542PLUS is widely used in medium-voltage and low-voltage power systems,substations,industrial power systems(such as manufacturing,chemical plants,etc.),wind farms,solar farms,rail transit systems,and urban infrastructure(such as hospitals,schools,commercial buildings,etc.)to protect key equipment from power failures and improve system reliability and stability.

IV.Main technical parameters(example)

AC input:up to 8 AC input channels,current and voltage sensors or traditional transformers can be connected.

Switch input/output:read switch input signals to obtain the status information of the auxiliary contacts of the primary equipment,and use switch output signals to send various command signals.

Fault recording:up to 8 AC input channels and 32 switch input signals can be recorded,with a sampling frequency of 1.2kHz,and a minimum recording length of 1 second and a maximum of 5 seconds.

V.Product advantages

Advanced technology:integrates multiple protection and measurement and control functions to meet various power system protection and control requirements.

Reliable performance:uses high-quality materials and manufacturing processes,with high reliability and stability.

Easy to expand:modular design allows users to configure and expand according to actual needs.

Easy to operate:user-friendly human-machine interface,supports multi-language display and touch operation,convenient for users to monitor and operate.





The company mainly imports PLC modules,programmable controllers,servo control systems and DCS spare parts,such as:ABB,AB(Rockwell),GE(General Electric),Bentley,Honeywell Er),Emerson.),Motorola,Invensys,Westinghouse,etc.The company has established close cooperative relations with many world-renowned PLC and DCS product maintenance service providers.We can purchase goods directly from abroad and provide equipment and spare parts from different countries and manufacturers.

We supply goods directly from abroad,without intermediaries,reducing the cost of use.

There is really no medium that can make a difference!!

Shenzhen Changxin Automation-sufficient supply,large spot quantity,guaranteed quality,you can buy with confidence and use with peace of mind~!

If you have any defects or needs for imported PLC and DCS spare parts,please contact our team,we will help you find reliable and high-quality products super quickly,while shortening delivery time to ensure that your equipment can operate normally in the right environment.Just in time.

Professionally provide:PLC programmable control system,distributed control system(DCS),safety instrument system(SIS),ESD system,vibration monitoring system,turbo compressor unit control system(CCS)and other PLC modules,various industrial control systems,system modules,CPU,IO module,DO module,AI module,DI module,network communication module,Ethernet module,motion controller,analog input module,analog output module,digital input module,digital output module,module redundancy,power module,relay output unit,relay input unit,processor unit.

Products are widely used in:electricity,petroleum,mine hoisting,ports,heating,gas,water supply,sewage treatment,metallurgy,papermaking,textile,chemical industry,water conservancy and other modern industrial fields!
